PV720A User’s Manual
31
Specifications
LCD Panel
17" TFT LCD module with wide-viewing angle,
0.264(H)x0.264 (V)mm pixel
[ Monitor ]
Effective display size
17" (43.2 cm diagonal)
Resolution (max.)
SXGA 1280x1024
Displayable colours
16.7M True color
Brightness
250 Cd/m2 (typical)
Contrast ratio
350:1 (typical)
Scan Frequency
Horizontal: 30 to 82 kHz automatically
Vertical: 50 to 75 Hz automatically
Response time
45 ms
Audio Input
1V(RMS), Max.
Audio Output
1W X 2
User controls
Power/Enter/Up/Down/Esc
Power Consumption
40 W Max.
<5 W Power Saving
[ OSD control options ]
Main menu
Volume Tuning, Auto-Tune, Color, Quality,
Position, Language, Recall
Sub-menu
Clock, Phase, Smoothing, Image Pos, OSD Pos
Input signal
Analog 0.7V peak to peak separate TTL Positive or
Negative
Power Supply
100~240 VAC, 50/60 Hz (automatically)
Plug & Play
DDC 1/2B
