English - 11
English - 10
Self Diagnosis
When the monitor doesn’t display, if you press any key, Self
Diagnosis screen is displayed. Self Diagnosis function checks if
the status of the monitor is No Signal or Out of range.
No Signal screen is displayed when the
D-Sub signal connector is not connected
or the status of the monitor is on DPMS
mode.
Out of Range screen is displayed when
the applied frequency is under or over
normal range.
Normal range
H : 30 - 107 KHz
V : 50 - 160 Hz
Reset the screen to the Factory Preset
Display Settings.
Display a RGB Color Bar to determine
whether the screen color is expressed
normally or not.
TEST PATTERN
RECALL
Display horizontal & vertical frequency
and polarity.
STATUS
POWER SAVER
YES : VESA DPMS operation.
NO : NO DPMS operation.
ICON CONTROL FUNCTION
Select a input signaling type between D-
sub and BNC connector.
BNC/D-SUB
Adjust the rotation when the screen is
tilted left or right.
ROTATION
Degaussing keeps the monitor free from
unwanted magnetism that can result in
color impurity.
DEGAUSS
Adjust the pin W control when the sides
of the screen are in a W shape.
PIN W CONTROL
