10. Side-Pincushion Circuit
Check the Base
waveform of the Q515
Yes
Pincusion distortion
is excessive or barrel
O.K
Select the
side-pincushion
icon in OSD menu,
and adjust acceptable
position.
Yes
Is the
pin 11 waveform of
IC501
correct?
No
No
Trouble in IC501
