6 SWITCHES Gigabit Ethernet Layer 3 Chassis Switches
DES-7200 Series
Gigabit Ethernet Layer 3 Chassis Switches
DES-7200 series chassis-based switch is an intelligent and high performance
multi-layer LAN device designed for enterprise, campus, and metropolitan area
networks (MAN). The switch is ideal for deployment in environments where
uninterrupted running of network applications and high level of performance,
security and control are required. It provides the flexibility of deploying Gigabit
and/or 10-Gigabit packet switching and routing.
Optional Accessories
I/O Modules
7200-24 12-Port 10/100/1000BASE-T + 12-Port Combo 1000BASE-T or SFP
7200-24G 12-Port SFP + 12-Port Combo 10/100/1000BASE-T or SFP
7200-24P 12-Port 10/100/1000BASE-T PoE + 12-Port Combo 1000BASE-T PoE
or SFP
7200-48 44-Port 10/100/1000BASE-T + 4-Port Combo 1000BASE-T or SFP
7200-48P 44-Port 10/100/1000BASE-T PoE + 4-Port Combo 1000BASE-T PoE
or SFP
7200-2XG 2-Port 10-Gigabit XFP
7200-4XG 4-Port 10-Gigabit XFP
Enhanced I/O Modules
7200-24G2XGE 12-Port SFP + 12-Port Combo 1000BASE-T or SFP + 2-Port
10-Gigabit XFP
7200-24GE 24-Port SFP
7200-48E 44-Port 10/100/1000BASE-T + 4-Port Combo 1000BASE-T or SFP
Extension Memory
7200-512RAM 512MB Additional RAM Module (for 7200-CM3/7200-CM4)
CPU Modules
7200-CM1 CPU Module with 96G Switching Capacity (for DES-7206-BASE)
7200-CM3 CPU Module with 96G Switch Capacity & Supports Advanced
Service Engine (for DES-7206-BASE)
7200-CM2 CPU Module with 192G Switching Capacity (for DES-7210-BASE)
7200-CM4 CPU Module with 192G Switching Capacity & Supports
Advanced Service Engine (for DES-7210-BASE)
Advanced Service Engines
7200-ASE2 ASE II for IPFIX Support
7200-ASE3 ASE III for MPLS Support
Redundant Power Supplies
7200-1200AC 1200W AC Redundant Power Supply
7200-1200DC 1200W DC Redundant Power Supply
7200-2000AC 2000W AC Redundant Power Supply
Fans
7206-FAN Fan Tray (for DES-7206-BASE)
7210-FAN Fan Tray (for DES-7210-BASE)
10-Gigabit Ethernet XFP Transceivers
DEM-421XT 10GBASE-SR, MMF, 300m
DEM-422XT 10GBASE-LR, SMF, 10km
DEM-423XT 10GBASE-ER, SMF, 40km
Gigabit Ethernet SFP Transceivers
DEM-310GT 1000BASE-LX, SMF/MMF, 10km/2km
DEM-311GT 1000BASE-SX, MMF, 550m
DEM-312GT2 1000BASE-SX, MMF, 2km
DEM-314GT 1000BASE-LH, SMF, 50km
DEM-315GT 1000BASE-ZX, SMF, 80km
DGS-712 1000BASE-T, Copper, 100m
Gigabit Ethernet WDM SFP Transceivers
DEM-330T/R 1000BASE-BX, SMF, 10km
DEM-331T/R 1000BASE-BX, SMF, 40km
Fast Ethernet SFP Transceivers
DEM-210 100BASE-FX, SMF, 15km
DEM-211 100BASE-FX, MMF, 2km
Fast Ethernet WDM SFP Transceivers
DEM-220T/R 100BASE-BX, SMF, 20km
Management Software
DV-600S D-View 6.0 Network Management System (Standard Edition)
DV-600P D-View 6.0 Network Management System (Professional Edition)
• InternetGroupManagementProtocol
(IGMP) Snooping
• RapidEtherRingProtection(RERP)
• DoubleVLAN(Q-in-Q)
• SelectiveQ-in-Q
• PrivateVLAN
• VirtualRouterRedundancyProtocol
(VRRP)
• IPv6ReadyPhase2
• OpenShortestPathFirst(OSPF)
• BorderGatewayProtocol(BGP)
• ProtocolIndependentProtocol-Dense
Mode (PIM-DM)
• ProtocolIndependentProtocol-Sparse
Mode (PIM-SM)
• QualityofService(QoS)
• MultiProtocolLabelSwitching(MPLS)
• VirtualRouting&Forwarding(VRF)
• IPFlowInformationExport(IPFIX)
• GlobalMAC-IPBinding
• CPUProtectionPolicy(CPP)
• 802.1XPort-basedAccessControl
• 802.1XMAC-basedAccessControl
• SimpleNetworkManagementProtocol
(SNMP)
DES-7206-BASE
•I/OModuleSlotx4
•CPUModuleSlotx2
•BuiltinFanTray
•BuiltinDustFilter
•AC/DCPowerSupplyOption
•RedundantPowerSupply
DES-7210-BASE
•I/OModuleSlotx8
•CPUModuleSlotx2
•BuiltinFanTray
•BuiltinDustFilter
•AC/DCPowerSupplyOption
•RedundantPowerSupply
