Networking Evolved
Push the limits of basic networking technology and experience the evolution in networking. Wirelessly share broadband Internet, boost
network performance, stay competitive in your online games with D-Link’s new cutting-edge GamerLounge™ Wireless 108G Gaming
Router
™, powered by GameFuel™ Priority Technology.
Fit for the True Online Gamer
· Introducing GameFuel ™ Priority Technology designed to provide the uninterrupted and latency-free gaming experience serious online
gamers expect
· Customized with game-centric features boasting maximum flexibility for configuration and performance
· Unparalleled 802.11g wireless performance
· Designed for the Gamers Network
Cutting-Edge Technology For Today and Tomorrow’s Gamers Network
· GameFuel ™ Priority powered platform reduces latency and boosts network efficiency and performance
· Intelligently manages and automatically prioritizes network traffic to better execute bandwidth-sensitive applications including VoIP and
multimedia applications
· Enhanced wireless technology for optimal range and connectivity – up to 108Mbps
1
· High-Performance CPU to support up to 1000 concurrent connections – ideal for P2P applications and multiplayer interactivity
· Enables multi-tasking between other applications without degradation in game connection
· Pre-configured ports to accommodate up to 256 policies for games and applications
· Customizable settings to add or modify new applications or game configurations
· Firmware upgrade notification feature keeps your new D-Link Gaming Router up to date
Intimidation Never Looked This Good
· One Fast Ethernet 10/100 WAN port which supports virtually all broadband Internet connections
· Four Gigabit Ethernet 10/100/1000 auto-sensing LAN ports
· 5dBi high-gain antenna for exceptional wireless signal coverage
· Fine-tuned web GUI enhancements for seamless device management
Play Your Games, Protect Your Network
· Protect your wireless data with support for both Wi-Fi Protected Access (WPA) and 128-bit Wired Equivalent Privacy (WEP)
· Integrated Stateful Packet Inspection (SPI) firewall and Network Address Translation (NAT) firewall help protect against hackers,
wardrivers, and other unauthorized users
· Create versatile Access Control policies to control network access based on time, date, websites, and/or applications
· Disable SSID Broadcast and MAC Filtering features protect against unauthorized access from your wireless network
· Supports Virtual Private Network (VPN) pass-through to create a secure connection to office networks
Package Contents
· DGL-4300 Wireless 108G Gaming Router
TM
· Detachable Antenna
· CAT5 Ethernet Cable
· Power Adapter (5V, 2.5A)
· Mounting Kit
· Vertical Stand
· CD-ROM with Manual
· Quick Installation Guide
Minimum System Requirements
· Cable or DSL Modem with Ethernet Port
To Change Default Settings
· PC with
>
1.2GHz Processor
>
256MB Memory
>
CD-ROM Drive
>
Ethernet Adapter with TCP/IP Protocol Installed
>
Windows
®
XP/2000/Me or
Mac
®
OS X v10.3/v10.2/v10.1
>
Internet Explorer v6 or Netscape
®
Navigator v7
Hardware Interface
· 4 x 10/100/1000 Auto-Sensing Gigabit
Ethernet LAN Ports
· 1 x 10/100 Auto-Sensing Fast Ethernet
WAN Port
· D-Link 108G Wireless Technology
Software Features
· GameFuel™ Priority – Technology
· Up to 256 Firewall Port Configurations
· Access Control Policies (Parental Controls)
· Internal and External System Logging
· Static / Dynamic Routing
· Oversized NAT table
· Email Alerts
· Wireless Distribution System (WDS)
Dimensions
· L = 7.5 inches (190.5mm)
· W = 4.6 inches (116.84mm)
· H = 1.375 inches (35mm)
Security
· WPA-Enterprise
· WPA-Personal
· 64/128-bit WEP
· MAC Filtering
External Antenna Type
· 1 - 5dBi detachable antenna
Standards
· IEEE 802.11g
· IEEE 802.11b
· IEEE 802.3
· IEEE 802.3u
LEDs
· Power
· WAN
· WLAN (Wireless Connection)
· LAN
Wireless Signal Rates
1
with Automatic Fallback
· D-Link 108G: 108Mbps
· 54Mbps · 48Mbps
· 36Mbps · 24Mbps
· 18Mbps · 12Mbps
· 11Mbps · 9Mbps
· 6Mbps · 5.5Mbps
· 2Mbps · 1Mbps
Power Input
· External Power Supply DC 5V, 2.5A
Warranty
· 1-Year
1
Maximum wireless signal rate derived from IEEE Standard 802.11g
specifications. Actual data throughput will vary. Network conditions
and environmental factors, including volume of network traffic,
building materials and construction, and network overhead lower
actual data throughput rate.
