1528L 15" LCD Medical Touchmonitor
Case/Bezel Color Dark gray or beige
B
ase Tall
Display Size: 15" diagonal
Type: Active matrix TFT LCD
Aspect ratio: 4 x 3
Useful Screen Area Horizontal: 11.98" (304 mm)
Vertical: 8.98" (228 mm)
Monitor Dimensions Width: 13.99" (355 mm)
(max, with tall stand) Height (inc. base): 13.8” (350 mm)
Depth (inc. base): 8” (203 mm)
Optimal (Native) Resolution 1024 x 768
O
ther Supported Resolutions 1024 x 768 at 60, 65, 70 or 75 Hz
8
32 x 624 at 75 Hz
8
00 x 600 at 56, 60, 72 or 75 Hz
7
20 x 400 at 70 Hz
7
20 x 350 at 70 Hz
6
40 x 480 at 60, 66 Hz (Mac), 72 or 75 Hz
Colors 16.2 million colors, 8 bit with dithering
Brightness LCD panel: 350 cd/m
2
(typical)
with AccuTouch: 287 cd/m
2
(typical)
with IntelliTouch: 322 cd/m
2
(typical)
R
esponse Time 8 ms (typical)
Viewing Angle Horizontal (left/right):
±75° or 150° total
(typical, from center) Vertical (up/down): 75°/50° or 125° total
Contrast Ratio 400:1
Input Video Format RGB analog; DVI-D
Input Video Signal Connector Mini D-Sub 15-Pin VGA type; DVI-D connector
Input Frequency Horizontal: 31-60 kHz
Vertical:56-75 Hz
Power Supply Type: External Power Adapter; DC output (line) voltage: 12.0V ± 0.75V; AC input (line)
voltage to DC adaptor: 100-240 VAC, 50/60 Hz; Power: 48 W max; Hospital grade power
cord for US/CAN; European power cord
Temperature Operating: 0°C to 40°C
Storage:- 20°C to 60°C
Humidity Operating: 20-80%
Storage: 5-95% non-condensing
Weight Weight with power adapter: 16.13 lbs (8.3 kg)
(approx., with all options) Weight w/o power adapter: 15.3lbs (6.9 kg)
Shipping Weight: 22.2 lbs ( 10.1 kg)
Warranty Monitor: 3 years
Backlight lamp life: min 40,000 hours to half brightness
MTBF: 50,000 hours minimum demonstrated
Agency Approvals FCC/IC/C-Tick Class B, UL/cUL Medical UL 60601-1(formerly 2601-1)/C22.2 No. 601.1, CE
Medical Device Directive EN60601-1, Demko Medical EN60601-1, CB Medical IEC 60601-1.
Includes EMC requirements EN/IEC 60601-1-2.
Speakers Two-watt/channel speakers located in display head
On-screen Display (OSD) OSD lockouts for power and user controls
User's Controls OSD control menu: menu, up, down, select, power
OSD controls: contrast, brightness, V-position, H-position, RGB, volume, Sharpness,
phase, clock, OSD H-position, OSD V-position, OSD time, auto adjust, OSD language
(English, French, German, Spanish, Japanese), input select
O
SD disable/
enable: po
w
er
, O
SD menu
Mounting Options 75 mm VESA mount
Removable base
T
yco Electronics reserves the right to change or update, without notice, any information contained herein;
to change, without notice, the design, construction, materials, processing or specifications of any products;
and to discontinue or limit production or distribution of any products.
AccuTouch, Elo TouchSystems, IntelliTouch, TE Logo, and Tyco Electronics are trademarks.
Copyright 2008 Tyco Electronics Corporation ELO-179 1/08
