Dot pitch, nominal 0.27 mm
Video bandwidth 67 MHz
Scanning
frequency
Horizontal: 30–70 kHz
Vertical: 50–160 Hz
Input video format Analog (no proprietary video card needed)
Input video signal
connector
Mini D-Sub 15-Pin (female)
Power supply 90–264 VAC, 50–60 Hz
Power dissipation 75 W max.
Temperature Operating: 0°C to 40°C
Storage: -40°C to 60°C
Humidity Operating: 10% to 90%
Storage: 10% to 90%
noncondensing
Weight
(approx.)
Net: 32 lb (14.5 kg)
Shipping: 37 lb (17.0 kg)
Warranty Monitor: 2 years
Touch technology: 2 years iTouch, 5 years
AccuTouch
Agency approvals UL, cUL, FCC, CE, CISPR22 Class B,
TÜV-GS, MPR II (ITE per IEC/EN 60950);
agency approval certificates (2.1 MB PDF)
Other features 100% light transmission (iTouch) with no
parallax
Digital on-screen display (OSD) with Lock-
Out capability
Power Save function
Rigid (removable) base
Innovative touchscreen sealing
VESA DDC 1/2 B Plug and Play
Touch
Technology
Touch
Interface
Surface
Treatment
Elo Part
Number
iTouch Serial Antireflective 045182-000
iTouch USB Antireflective 454000-000
AccuTouch Serial Antiglare 872230-000
AccuTouch USB Antiglare 421496-000
Page 2 of 3
3000 Series Elo Entuitive 1725C 17" CRT Desktop Touchmonitor
5/12/03
http://www.elotouch.com/products/crts/1725c.asp
