SecureStack C2 Installation Guide xi
About this Guide
Thisguideprovidesanoverview,installationandtroubleshootinginstructions,and
specificationsfortheEnterasysSecureStackC2RPS‐SYSredundantpowersystem
components:chassis(C2RPS‐CHAS8),powersupplymodule(C2RPS‐PSM),DCpower
cables(C2RPS‐PSMCable),andACpowercords.
Using This Guide
Readthroughthisguidecompletelytofamiliarizeyourselfwithitscontentsandgainan
understandingofthefeaturesandcapabilitiesoftheRPScomponents.Ageneralworking
knowledgeofdatacommunicationsnetworksishelpfulwhensettingupanRPS.
Structure of This Guide
Thisprefaceincludesanoverviewofthisguideanddetailstheconventionsusedinthis
guide.Thisguideisorganizedasfollows:
Chapter 1,Introduction,discussesthefeaturesandcapabilitiesoftheRPS.Thischapter
alsoprovidestheinstructionsforobtaininghelpfromEnterasysNetworks,ifneeded.
Chapter 2,Installation,providesinstructions
toinstallanRPSintoastandard19‐inch
rack.Thisinvolvesinstallingthechassis,onetoeightPSMs,PSMinterconnectingcables,
andACpowercords.
Appendix A,Specifications,providesthespecificationsforthechassis,PSM,PSMcable,
RedundantPowerSupplyconnectorpinoutdescriptions,andComplianceStandards.
Note: In this document, the following terms are used:
• RPS refers to the complete SecureStack C2RPS-SYS redundant power system.
• Chassis refers to the C2RPS-CHAS8 chassis.
• PSM refers to the C2RPS-PSM power supply module.
• PSM cable refers to the C2RPS-PSM Cable (12 Vdc power cable).
