C
ONTROLS AND CONNECTORS
VIDEO CABLE
Connecting the D-Sub Cable: Connect one end of the 15-pin D-Sub cable to
the back of the monitor and connect the other end to the computer’s D-Sub
port.
Connecting the Power Cord: Plug the AC-power cord into the External
Adapter. Then plug the DC-jack power cable into DC-IN Inlet.
Caution: If the AC outlet is not grounded (with three holes), install the proper
grounding adapter (not supplied).
Figure 2 Connecting Cables
1. DC-Jack Power Cable
2. Signal Cable
3. AC Power Cord
6
