Standard Interface Modules
EPSON
RS-232 Interface
Modules
* Electronic Industries Association
** Larger storage for electronic journal is possible by special order
DB-25 Connector
DB-9 Connector
Module Installation
To find out more about our line of Connect-It Interfaces talk to your EPSON Sales Representative.
Specifications are subject to change without notice.
Conforms to OLE POS specifications.
Module Specifications
RS-232 Module
EIA* communication standard RS-232
Connector DB-25
Communication speed 2400 bps up to 19200 bps
RS-485 Module
EIA communication standard RS-485
Connector DB-25
Communication speed 2400 bps up to 19200 bps
Serial Buffer Module
Buffer size Up to 24 KB
Communication speed Can be set from 300 bps up to 38400 bps
Connector DB-25
EIA communication standard RS-232
Settings
Many settings are available via jumper
settings and even more settings are available
via a software application program
Programmable
Can be easily upgraded in the field via
software utility program
Serial Annunciator Module
EIA communication standard RS-232
Connector DB-25 or DB-9
Communication speed 2400 bps up to 19200 bps
Audio annunciator volume 80 dB
Universal Serial with EJ
EIA communication standard RS-232
Connector DB-25
Communication speed 2400 bps up to 19200 bps
Electronic journal** 2 MB (approx. 6¼ rolls of journal paper)
Epson America, Inc. • 3840 Kilroy Airport Way • Long Beach, CA 90806 • Product Purchase Referral Line: (562) 290-5304
© 2001 Epson America, Inc. EPSON and ESC/POS are registered trademarks of Seiko Epson Corporation. Connect-It and QuickPass are trademarks of Epson America, Inc.
All other trademarks are the property of their respective companies. EPSON is a member of the OPOS committee.
!$
