Eton FR370 Power Supply User Manual



SOLARLINKFR370 OWNER’S MANUAL
9
ACTIVATING AND DEACTIVATING
THE ALARM TIME
Press <ON/OFF/ALARM> button shortly to activate or deactivate the alarm.
If the alarm function is activated, the symbol “
“ will be on the display.
When the alarm time is reached, the unit will beep. If the alarm function
is deactivated, the alarm symbol “
“ will disappear.
A M 0 8
:
30
ALL COUNTY
SNOOZE FUNCTION
When the alarm activates, press <SNOOZE> button shortly deactivates it
for 5 minuetes (the symbol “
“ will appear in the display), then it starts
to beep again.
AM/FM BROADCAST RECEPTION
Turn on the radio. Press the AM/FM button, AM or FM will appear on the
display with the frequency to the right of it, in KHz for AM and in MHz for
FM. Press the
buttons quickly to tune individual frequencies, hold to
tune automatically to the next frequency. Pull up the telescopic antenna to
hear FM frequencies.
The AM ferrite bar antenna is built-in to the radio, so no telescopic antenna
is needed for AM reception.
• FM tuning range: 87.5 to 108 MHz.
• AM tuning range: 520 to 1710 KHz.
RECEPTION OF NOAA
WEATHER BAND FREQUENCIES
To hear your local weather station, pull up the antenna, turn on the radio
and press the WB button located above the display. Turn up the volume and
press the
buttons to go through all 7 weather channels. WB and CH
appear at the top of the display, with 1-7 next to CH. You’ll probably only
hear one channel, but if you hear a weather broadcast on more than one,
select the strongest. The strongest one will usually be your local weather
station. Below are the frequencies that correspond to the radio’s channels:
