CVEQ1 Series
Di str ibu tio n A mp lif ier s — li ne Dr ive rs
sPeCifiCAtions
viDeo
Gain ................................ -6 dB to +6 dB, adjustable: 0.5 V to 2.0 V ±10% with input at 1 volt
Equalization / Peaking gain ... 4.5 dB max. @ 8 MHz
Bandwidth ........................ 185 MHz (-3 dB)
Differential phase error ........ 1º at 3.58 MHz
Differential gain error .......... 0.07% at 3.58 MHz
viDeo inPut
Number / Signal type ........... 1 composite video
Connectors ....................... 1 female BNC
Nominal level .................... 1 Vp-p
Minimum / Maximum levels ... Analog: 0.3 V to 2.0 Vp-p with no offset at unity gain
Impedance ........................ 75 ohms
Return loss ....................... <-30 dB @ 5 MHz
viDeo outPut
Number / Signal type ........... 1 equalized composite video
Connectors ....................... 1 female BNC
Nominal level .................... 1 Vp-p at unity gain
Minimum / Maximum levels ... 0.3 V to 2.0 Vp-p
Impedance ........................ 75 ohms
Return loss ....................... <-30 dB @ 5 MHz
DC offset .......................... ±50 mV with input at 0 offset
synC
Standards ......................... NTSC 3.58, NTSC 4.43, PAL, SECAM
AuDio
Gain ................................ Unbalanced output: 0 dB; balanced output: +6 dB
Frequency response ............ 20 Hz to 20 kHz, ±0.5 dB
THD + Noise ...................... 0.025% @ 1 kHz, 0.020% @ 20 kHz at nominal level
S/N ................................. >86 dB at output 6 dB, balanced
Stereo channel separation .... >75 dB @ 20 Hz to 20 kHz
AuDio inPut
Number / Signal type ........... 1 stereo unbalanced
Connectors ....................... 2 RCA female
Impedance ........................ >10k ohms unbalanced, DC coupled
Nominal level .................... -10 dBV (316mV)
Maximum level .................. +6 dBV, (balanced) at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
AuDio outPut
Number / Signal type ........... 1 stereo, balanced/unbalanced
Connectors
CVEQ1 ............................. (1) 3.5 mm captive screw connector, 5 pole
CVEQ1 AAP
........................ (1) 3.5 mm direct insertion captive screw connector, 5 pole
Impedance ........................ 50 ohms unbalanced, 100 ohms balanced
Nominal level .................... -2 dBu (632 mV), balanced output
Maximum level (Hi-Z) ........... >+16 dBu, balanced at 1% THD+N
Maximum level (600 ohm) ..... >+9 dBm, balanced at 1% THD+N
GenerAL
External power supply ......... 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable;
to 12 VDC, 1 A (max.), regulated
Power input requirements ..... 12 VDC, 0.4 A
Temperature / Humidity ........ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount ...................... No
Enclosure type ................... Metal
Enclosure dimensions
CVEQ1 ............................. 1.2" H x 3.5" W x 1.8" D
3.0 cm H x 8.9 cm W x 4.6 cm D
(Depth excludes connectors.)
CVEQ1 AAP
Plate ................................ 1.4" H x 3.5" W x 0.1" D
( 2.8 cm H x 8.9 cm W x 0.3 cm D) (double space high AAP plate)
Circuit board
....................... 1.1" H x 2.7" W x 1.7" D
(2.8 cm H x 6.9 cm W x 4.3 cm D)
(Height includes connectors, but not cables.)
CVEQ1 WM
Plate ................................ 4.5" H x 2.8" W x 0.1" D
(11.4 cm H x 7.1 cm W x 0.3 cm D) (1 gang)
Circuit board
....................... 2.7" H x 1.1" W x 1.7" D
(6.9 cm H x 2.8 cm W x 4.3 cm D)
(Width includes connectors, but not cables.)
Product weight
CVEQ1, CVEQ1 AAP
.............. 0.2 lbs (0.1 kg)
CVEQ1 WM
........................ 0.3 lbs (0.1 kg)
Shipping weight
CVEQ1, CVEQ1 AAP
.............. 2 lbs (1 kg)
CVEQ1 WM
........................ 3 lbs (2 kg)
Vibration .......................... ISTA 1A in carton (International Safe Transit Association)
Listings ............................ UL, CUL
Compliances ..................... CE, FCC Class A
MTBF .............................. 30,000 hours
Warranty .......................... 3 years parts and labor
NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.
