IPL T S2
Two Serial Port IP Link
®
Ethernet Control Interface
unIquE fEAturEs
•
Two bidirectional RS-232, RS-422, or RS-485 serial ports
•
Support for Power over Ethernet, PoE 802.3af
IPL T S4
Four Serial Port IP Link
®
Ethernet Control Interface
unIquE fEAturEs
•
Four bidirectional RS-232, RS-422, or RS-485 serial ports
•
Support for Power over Ethernet, PoE 802.3af
IPL T S6
Six Serial Port IP Link
®
Ethernet Control Interface
unIquE fEAturEs
•
Two bidirectional RS-232, RS-422, or RS-485 serial ports
•
Four bidirectional RS-232 serial ports
•
Support for Power over Ethernet, PoE 802.3af
IPL T S1
One Serial Port IP Link
®
Ethernet Control Interface
unIquE fEAturEs
•
One bidirectional RS-232 serial port
•
--- 7.25 MB of available flash memory
•
Low-profile form factor
•
Optional MBU 125 1U, 1/2 Rack Width, Under-Desk Mount Kit available,
part # 70-077-01
IPL T S Series
IP LInk
®
Products
modEL VErsIon dEscrIPtIon PArt #
IPL T S6 Six serial ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-544-84
modEL VErsIon dEscrIPtIon PArt #
IPL T S4 Four serial ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-544-83
modEL VErsIon dEscrIPtIon PArt #
IPL T S2 Two serial ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-544-81
modEL VErsIon dEscrIPtIon PArt #
IPL T S1 One serial port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-801-81
