Control System
Plasma
Plasma
Projector
Sound System
Extron
VSC 500
Video Scan
Converter
VCR
PC
Laptop
Laptop
Audio In
Extron
DVS 304
Digital Video
Scaler
DVD
Extron
MVX Plus 128 VGA A
VGA & Audio
Matrix Switcher
Audio In
Audio Out
Ethernet
V
S
C
5
0
0
S
C
A
N
C
O
N
V
E
R
T
E
R
S
I
Z
E
M
I
N
/
M
A
X
N
E
X
T
M
E
N
U
F
R
E
E
Z
E
R
E
S
E
T
I
R
C
E
N
T
E
R/
P
A
N
/
S
I
Z
E
F
R
O
N
T
P
A
N
E
L
L
O
C
K
O
U
T
R
S
-
2
3
2
P
R
O
T
E
C
T
C
H
1
C
H
2
A
P
A
7
5
4
A
U
D
I
O
P
O
W
E
R
A
M
P
L
I
F
I
E
R
C
L
I
P
N
O
R
M
S
I
G
N
A
L
LAN
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
deScriPtion
The MVX Plus 128 VGA A is a 12 input, eight output matrix switcher designed to route high
resolution computer-video and stereo audio signals. It offers the performance of a wideband
switcher with the convenience of 15-pin HD connectors for all computer-video input and
output connections. Balanced or unbalanced stereo audio is input and output on captive screw
connectors. Using pre-terminated cable assemblies, such as Extron's VGA Cables, eliminates
crimping and makes installations faster and easier.
Housed in a compact, 2U metal enclosure, the MVX Plus 128 VGA A includes RS-232 and
IP Link
®
Ethernet control capability. A standard QS-FPC
™
- QuickSwitch Front Panel Controller
allows for simple, touch-of-a-button input and output selection directly from the front panel. The
flexibility to control the matrix switcher from a remote location is also possible using the optional
MKP 2000 and MKP 3000 Series Matrix Switcher X-Y Remote Control Panels.
The MVX Plus 128 VGA A features exclusive Extron technologies, such as ADSP
™
- Advanced
Digital Sync Processing, an all-digital process that corrects and restores the sync signal as
it passes through the switcher, and DSVP
™
- Digital Sync Validation Processing for verifying
active sources.
MVX Plus 128 VGA A
Vga/audio Matrix SwitcherS
control / reMote
—
Switcher
Serial control port ............... 1 RS-232 or RS-422, 9-pin female D connector
Baud rate and protocol ......... 9600 (default), 19200, 38400, 115200 baud (adjustable);
8 data bits, 1 stop bit, no parity
Serial control pin configurations
RS-232: 2 = TX, 3 = RX, 5 = GND
RS-422: 2 = TX-, 3 = RX-, 5 = GND, 7 = RX+, 8 = Tx+
Ethernet control port ........... 1 RJ-45 female connector
Ethernet data rate ............... 10/100Base-T, half/full duplex with autodetect
Ethernet protocol ................ ARP, DHCP, ICMP (ping), TCP/IP, Telnet, HTTP
Program control ................. Extron’s control/configuration program for Windows
®
Extron’s Simple Instruction Set (SIS
™
)
Microsoft
®
Internet Explorer, Telnet
GenerAl
Power .............................. 100 VAC to 240 VAC, 50/60 Hz, 30 watts, internal, universal
Temperature / Humidity ........ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +113 °F (0 to +45 °C) / 10% to 90%, noncondensing
Cooling ............................ Convection, vented
Rack mount ...................... Yes, with included brackets
Enclosure type ................... Metal
Enclosure dimensions .......... 3.5" H x 19.0" W x 9.4" D (2U high, full rack wide)
8.9 cm H x 48.3 cm W x 23.9 cm D
(Depth excludes connectors. Width includes rack ears.)
Product weight .................. 14.4 lbs (6.5 kg)
Shipping weight ................. 21 lbs (10 kg)
DIM weight (International) ....... 25 lbs (12 kg)
Vibration .......................... ISTA 1A in carton (International Safe Transit Association)
Listings ............................ UL, CUL
Compliances ..................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF .............................. 30,000 hours
Warranty .......................... 3 years parts and labor
NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.
SPecificAtionS
Video
Routing ............................ 12 x 8 matrix
Gain ................................ Unity
Bandwidth ........................ >300 MHz (-3 dB) , fully loaded
0 - 10 MHz: no more than +0.1 dB to -0.1 dB
0 - 130 MHz: no more than +0.8 dB to -0.8 dB
Crosstalk .......................... -80 dB @ 1 MHz, -55 dB @ 10 MHz, -45 dB @ 30 MHz, -37 dB @ 100 MHz
Switching speed ................. 200 ns (max.)
Video inPut
Number / Signal type ........... 12 RGBHV, RGBS, RGsB, RsGsBs, HDTV component video, component video,
S-video, composite video
Connectors ....................... 12 female 15-pin HD
Nominal level .................... 1 VP-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum / Maximum levels ... Analog: 0.5 V to 2.0 Vp-p with no offset
Impedance ........................ 75 ohms
Return loss ....................... <-30 dB @ 5 MHz
DC offset (max. allowable) ....... 1.5 V
Video outPut
Number / Signal type ........... 8 RGBHV, RGBS, RGsB, HDTV component video, component video, S-video,
composite video (follows input type)
Connectors ....................... 8 female 15-pin HD
Nominal level .................... 1 VP-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum / Maximum levels ... 0 V to 2.0 Vp-p (follows input)
Impedance ........................ 75 ohms
Return loss ....................... -30 dB @ 5 MHz
DC offset .......................... ±5 mV with input at 0 offset
Switching type ................... Triple-Action
™
Sync
Input type ......................... RGBHV, RGBS, RGsB, RsGsBs
Output type ....................... RGBHV, RGBS, RGsB, RsGsBs (follows input)
Tri-level on Y, R-Y, B-Y channels (component video 720p, 1080i, 1080p)
Bi-level on Y channel (for all other component video rates)
Input level ........................ 0.5 V to 5.0 Vp-p, 4.0 Vp-p normal
Output level ...................... AGC to TTL: 4.0 V to 5.0 Vp-p, unterminated
Input impedance ................ 510 ohms
Output impedance .............. 75 ohms
Max input voltage ............... 5.0 Vp-p
Max. propagation delay ........ 30 ns
Max. Rise / Fall time ............ 4 ns
Polarity ............................ Positive or negative (follows input)
Audio
Routing ............................ 12 x 8 stereo matrix
Gain ................................ Unbalanced output: -6 dB; balanced output 0 dB
Frequency response ............ 20 Hz to 20 kHz, ±0.05 dB
THD + Noise ...................... 0.03% @ 1 kHz at nominal level
S/N ................................. >90 dB, balanced, at maximum output (21 dBu), unweighted
Crosstalk .......................... <-80 dB @ 1 kHz, fully loaded
Stereo channel separation .... >80 dB @ 1 kHz
CMRR .............................. >75 dB @ 20 Hz to 20 kHz
Audio inPut
Number / Signal type ........... 12 stereo, balanced/unbalanced
Connectors ....................... (12) 3.5 mm captive screw connectors, 5 pole
Impedance ........................ >10k ohm, balanced/unbalanced, DC coupled
Nominal level .................... 0 dBV (316 mV), 0 dBu (775 mV)
Maximum level .................. +19.5 dBu, (balanced or unbalanced) at 0.01% THD+N
Input gain adjustment .......... -18 dB to +24 dB, adjustable per input by RS-232/422, Ethernet, or front panel
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio outPut
Number / Signal type ........... 8 stereo, balanced/unbalanced
Connectors ....................... (8) 3.5 mm captive screw connectors, 5 pole
Impedance ........................ 50 ohms unbalanced, 100 ohms balanced
Gain error ......................... ±0.1 dB channel to channel
Maximum level (Hi-Z) ........... >+21 dBu, balanced or unbalanced at 0.10%THD+N
Maximum level (600 ohm) ..... >+15 dBm, balanced or unbalanced at 0.10%THD+N
Output volume range ........... 0 to 64 (-75.8 dB to 0 dB) in 1 dB increments from steps 1 to 64, 12 dB
increment from step 0 to 1
