KP 6
Keypad Remote Control
deScriPtion
The Extron KP 6 is a keypad remote control designed to switch the inputs on the Extron SW VGA
and SW RGBHV Series of switchers, as well as four and six input models of the SW AV Series
of switchers, that utilize a 9-pin contact closure connection. A 25-foot (7.5 meters) cable is
included to connect the switcher's 9-pin remote control port to the KP 6.
UCM 10X8P
Universal Controller Mounting Plate Kit
deScriPtion
The Extron UCM 10X8P mounting plate kit is designed for use with Extron MLC - MediaLink
™
Controllers and SCP - Secondary Control Panels installed in a lectern mount. Available in
black, white, and RAL9010 white, the UCM 10X8P is a universal controller mounting plate kit
with openings to accommodate up to eight single space AAP - Architectural Adapter Plates.
It can be mounted in a wall, desk, or lectern using an external wall box or Hoffman box,
model # A-SE10X8X4. MediaLink
™
Controllers, Secondary Control Panels, lectern mounts,
external wall boxes, and AAPs are sold separately.
Dimensions: 8.25" H x 10.25" W x 0.1" D (21.0 cm H x 26.0 cm W x 0.25 cm D)
Control Panels (continued)
Switcher Remote Control Panels
SwItcher AcceSSorIeS
modeL VerSion deScriPtion PArt #
KP 6 Keypad Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60-111-20
modeL VerSion deScriPtion PArt #
UCM 10X8P Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70-341-02
279
