2.2 Connection to Main Unit
As shown in Figure 2.2, use an IF cable to connect the 10BASE-T LAN adapter to the
main unit (sold separately).
■ Connection to main unit
As shown in Figure 2.2, use an IF cable to connect the 10BASE-T LAN adapter to the main unit
(sold separately).
Figure 2.2 Connection to main unit
F9210000I 01A
LAN
LAN ADAPTOR
10BASE-T
COM PORT
RESET
COMPORT
RS232C
TRIG
EMUL
POWER
ACIN
×
Main unit
IF cable
10BASE-T LAN adaptor
