DOCKING AND UNDOCKING THE COMPUTER
Vertical Walls
with your hand when you release the
button.
4. Rotate the top of the computer out
Figure 1
plate is spring loaded and should raise
Figure 4
Figure 3
Figure 2
of the dock to remove.
extended battery or card slot
attachment on the back side, you will
need to remove the guide block from
the face of the dock before inserting
the computer.)
3. Push downward on the slide plate
be used for security purposes.
(Note: If your FZ-G1 computer has an
4. (Optional) The key lock can now
to latch the dock. (See Figure 4)
1. Turn the computer off.
2. With the slide plate in the open
position, insert the bottom of the
computer into the docking station.
Make sure the guide tabs are lined up
with the pockets on the back side of
the computer.
Rotate the top of the comptuter under
the top hooks until the computer is
resting on the two vertical walls sticking
out from the slide plate.
(see Figues 1, 2 & 3)
TO UNDOCK THE COMPUTER
1. Turn the computer off.
2. Unlock if locked.
3. Press the Latch Button. The slide
Guide tabs
Guide Block
