B. DTMF Methods
Under Profile pages, there are three DTMF modes to choose from:
y DTMF in-audio
y DTMF via RTP (RFC2833)
y DTMF via SIP INFO
One or more DTMF methods can be selected at the same time.
C. Preferred VOCODER (Codec)
Under Profile pages, user can choose from the following different codecs:
PCMU (G711u), PCMA (G711a), G729A/B/E, G723, G726-16/24/32/40 and iLBC.
D. Firmware Upgrade
Under Advanced Settings page, enter “Firmware Server Path” (IP address or FQDN) under “Firmware
Upgrade and Provisioning” field. Select upgrade protocol TFTP, HTTP or HTTPS accordingly. By default,
“Always Check for New Firmware at Boot up” is selected.
E. Factory Reset
Below are the steps to reset the unit to factory default via the reset button.
1. Unplug the Ethernet cable.
2. Locate a needle sized hole on the back panel of the gateway unit next to the Power connection.
3. Enter a pin in this hole, and press for about 10 seconds till LED changes and a minor click sound.
4. Take out the pin. All configuration settings are restored to factory settings.
