Using the On-Screen Display (OSD)
Use the On-Screen Display (OSD) to adjust the screen image based on your viewing preferences. To
access the OSD, do the following:
1. If the monitor is not already on, press the Power button to turn on the monitor.
2. To access the OSD menu, press the Menu button. The OSD Main Menu displays.
NOTE: You need to touch the bar area on the front panel to display the front panel button
icons.
3. To navigate through the Main or sub-menu, press the + (Plus) button on the monitor's front panel
to scroll up, or the – (Minus) button to scroll in reverse. Then press the OK button to select the
highlighted function.
NOTE: The menu moves to the top if you scroll down at the bottom of the selections. The
menu moves to the bottom if you scroll up at the top of the selections.
NOTE: The slider bars on the front panel between the Plus (+) and Minus (–) buttons can also
be used for navigating menu items and making OSD control adjustments.
4. To adjust the scale of a selected item, press the + or – button, or use the slider bar.
5. Select Save and Return. If you don't want to save the setting, select Cancel from the sub-menu
or Exit from the Main Menu.
6. Press the Menu button to exit the OSD.
NOTE: When a menu is displayed, if the buttons are untouched for 30 seconds (factory
default), adjustments and settings are saved and the menu closes.
OSD Menu Selections
The following table lists the on-screen display (OSD) menu selections and their functional
descriptions. After changing an OSD menu item, and if the menu screen has these options, you may
choose to:
●
Cancel — to return to the previous menu level.
●
Save and Return — to save all changes and return to the OSD Main Menu screen. This Save
and Return option is active only if you change a menu item.
●
Reset — to change back to the previous setting.
Icon Main Menu Options Sub-menu Options Description
Brightness Adjusts the brightness level of the
screen.
Contrast Adjusts the contrast level of the screen.
Color Selects the screen color. The factory
default is 6500 K or Custom Color,
depending on the model.
6500 K Changes to slightly reddish white.
9300 K Changes to slightly blueish white.
ENWW Using the On-Screen Display (OSD) 15
