Operating and
Operating andOperating and
Operating and
Performance
PerformancePerformance
Performance
Specifications for RJ-45
Specifications for RJ-45Specifications for RJ-45
Specifications for RJ-45
Patch Panel 2 with Fiber
Patch Panel 2 with FiberPatch Panel 2 with Fiber
Patch Panel 2 with Fiber
Channel pass through
Channel pass throughChannel pass through
Channel pass through
Dimensions
DimensionsDimensions
Dimensions
Height
10.405 in (26.43 cm)
Width
1.535 in (3.899 cm)
Depth
27.697 in (70.35 cm)
Capability
CapabilityCapability
Capability
IEEE 802.2, 802.3, 802.3u
Network Transfer Rate
Network Transfer RateNetwork Transfer Rate
Network Transfer Rate
10 Base-T (half-duplex)
10 Mbps
10 Base-T (full-duplex)
20 Mbps
100 Base-TX (half-duplex)
100 Mbps
100 Base-TX (full-duplex)
200 Mbps
1000 Base-TX (full-duplex)
1000 Mbps
Fiber Channel SAN
Fiber Channel SANFiber Channel SAN
Fiber Channel SAN
Velio VC1070 re-timer
Auto-rate negotiate between 2G and 1G
Connector
ConnectorConnector
Connector
Network
RJ-45 in the back.
Fiber Channel SAN
Pluggable SFP optical slot in the front.
Cable Support
Cable SupportCable Support
Cable Support
10 Base-TX
Categories 3, 4, or 5 UTP (2 or 4 pair);
up to 328 ft (100 m)
100 Base-TX
Category 5 UTP (2 pair); up to 328 ft/100 m
1000 Base-TX
Category 5E (4 pair); up to 328 ft (100 m)
Fiber Channel
SFP optical cable
EMI
EMIEMI
EMI
FCC Class A
ICES-003 Class A
AS/NZS 3548 Class A
VCCI Class A
NOTE:
NOTE: NOTE:
NOTE:
Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No
direct sunlight. Upper operating limit is 10,000 ft (3,048 m) or 70Kpa/10.1 psia. Upper non-operating
limit is 30,000 ft (9,144 m) or 30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a
maximum temperature of 113° F (45° C). Altitude maximum for storage is 70 KPa.
Operating and
Operating andOperating and
Operating and
Performance
PerformancePerformance
Performance
Specifications for RJ-45
Specifications for RJ-45Specifications for RJ-45
Specifications for RJ-45
Patch Panel
Patch PanelPatch Panel
Patch Panel
Dimensions
DimensionsDimensions
Dimensions
Height
10.405 in (26.43 cm)
Width
1.535 in (3.899 cm)
Depth
27.697 in (70.35 cm)
Capability
CapabilityCapability
Capability
IEEE 802.2, 802.3, 802.3u
Network Transfer Rate
Network Transfer RateNetwork Transfer Rate
Network Transfer Rate
10 Base-T (half-duplex)
10 Mbps
10 Base-T (full-duplex)
20 Mbps
100 Base-TX (half-duplex)
100 Mbps
100 Base-TX (full-duplex)
200 Mbps
1000 Base-TX (full-duplex)
1000 Mbps
Connector
ConnectorConnector
Connector
Network
RJ-45 in the back
Cable Support
Cable SupportCable Support
Cable Support
10 Base-TX
Categories 3, 4, or 5 UTP (2 or 4 pair);
up to 328 ft (100 m)
100 Base-TX
Category 5 UTP (2 pair); up to 328 ft (100 m)
1000 Base-TX
Category 5E (4 pair); up to 328 ft (100 m)
Power Requirements
Power RequirementsPower Requirements
Power Requirements
200 mA at + 5V DC; 500 mA at -48V
Temperature Range
Temperature RangeTemperature Range
Temperature Range
Operating
50° to 95° F (10° to 35° C)
Non-operating
-22° to 140° F (-30° to 60° C)
QuickSpecs
HP ProLiant BL25p Server Blade
HP ProLiant BL25p Server BladeHP ProLiant BL25p Server Blade
HP ProLiant BL25p Server Blade
Technical Specifications
DA - 12160 North America — Version 7 — June 27, 2005
Page 38
