Humidity, Non-
operating
85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
Configuration Utilities HP Connection Manager
LED Activity LED Off – Radio Off;
Solid LED On – Radio On
Intel WiFi Link 5100 Wireless LAN
Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (draft 2.0)*
* The specifications for 802.11n draft 2.0 are draft specifications and are
not final. If the final specifications differ from the draft specifications, it
may affect the ability of the notebook to communicate with other 802.11n
WLAN devices. In countries where n draft 2.0 is not allowed, this
capability is not enabled.
Interoperability Wi-Fi certified (802.11abg only)
Cisco Compatible Extensions Program compliant (802.11abg only) with
Microsoft Windows Vista and XP (details at:
http://www.hp.com/go/notebooks/WLAN)
Tested with wireless access points from several major manufacturers
(details at: http://www.hp.com/go/notebooks/WLAN/draft-n)
Frequency Band 2.4 GHz and 5 GHz
Antenna Structure 1 transmit; 2 receive (1x2)
Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (draft): 66 possible data rates, ranging from 6 Mbps to 300
Mbps, depending on the combination of Bandwidth, Modulation Coding
Scheme, and Guard Interval used, as defined in IEEE 802.11n (draft)
specification
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES (support for key sizes of 128, 192, and 256 bits), 802.1x
authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-
MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible Extensions
Program Version 4) with Microsoft Windows Vista and XP only.
Sub-channels Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power (for CCK)
2
15 dBm
Output Power (for
OFDM; power varies by
data rate)
2
15 dBm
Power Consumption Transmit: 2.3 Watts (average, with one spatial streams)
Receive: 1.9 Watts (average with two receive chains)
Idle mode
3
: 30 mW (average)
Radio off: 20 mW (max)
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
300 Mbps: -68 dBm, 54 Mbps: -74 dBm, 6 Mbps: -90 dBm
Antenna Connections 3 U.FL type connectors, 50 ohm nominal impedance
Range 802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area
150 feet – Indoor, Office environment
802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor PCI-Express MiniCard
Weight 0.013 lb (6 g)
