Hardware Reference Guide www.hp.com 2–13
Hardware Upgrades
9. Install the expansion card by carefully holding the card just above
the expansion slot on the system board, then moving the card
toward the rear of the chassis so that the bracket on the card is
aligned with the open slot on the rear of the chassis 1. Gently
press the card straight down into the expansion slot on the system
board 2.
✎
Be sure not to scrape other components in the chassis when installing
an expansion card.
Installing an Expansion Card
✎
When installing an expansion card, press firmly on the card so that
the whole connector seats properly in the expansion card slot.
