HP Ultra VGA 1280 User’s Guide
Setting Up Your Display
4 English
Setting Up Your Display
Where to Place the Display
Place your display on a flat sturdy surface.
Ensure the operating site is free from excessive heat, moisture, and
sources of electromagnetic fields. Sources of electromagnetic fields
include transformers, motors, and other displays.
Connecting the Cables
1
Before you connect any cables, refer to the safety instructions at the
beginning of this manual and make sure your PC and display are
switched off.
2
Connect the video cable (it has a 15-pin plug) to the video outlet on
your PC. Tighten the thumbscrews on the plug.
3
Connect the power cord to the display.
4
Plug the power cord into the power outlet.
NOTE The location of your PC’s video outlet may be different to the one shown
in the diagram. Refer to the manual that came with your PC, if
necessary.
Video cable
Power cords
