HP Ultra VGA 1280 User’s Guide
Using Your Display
To adjust the displayed image if its vertical edges do not appear
parallel, press once and select the trapezoid option using the
adjustment controls. Use the and control buttons again to
correct for any distortion.
To adjust the displayed image if its vertical edges appear tilted, press
twice, and reshape using the and adjustment controls.
Depending on the orientation of your display, for example, whether it
faces north or south, you may experience some rotation of the image.
This effect is due to the influence of the earth magnetic field and is
normal for all displays. To adjust the displayed image if it appears to be
rotated, press twice and select the tilt option using the adjustment
controls. Use the and adjustment controls again to re-orient the
displayed image.
SETTING
INFORMATION
To obtain information on the video modes, image refresh rates and
screen resolutions supported by your display, press twice and use
and to scroll through the list.
Setting the Amount of Displayed Information
To set the amount of displayed information, change the screen
resolution of your PC. The higher the screen resolution, the more
information you can see on the screen. It is recommended that you use
a resolution of 1024
×
768 at 85 Hz. This gives easy-to-read characters,
a large amount of displayed information, and a flicker-free image.
You can make adjustments to the displayed image and they are
automatically saved for the resolution you are using. For example, if
you adjust your display when working in SVGA those settings are saved
for SVGA. If you then work in VGA and change the image settings, they
are saved for VGA. The next time you switch back to SVGA, your
previous settings are used automatically.
To find out which resolutions are supported by your display, refer to
“What Video Modes are Supported” on page 9. To change the screen
resolution, please refer to the manual that came with your PC or your
operating system documentation, if necessary.
