Video Cable Length
27 in (68.6 cm)
Power
Input Voltage
100 ~ 240 VAC
Nominal Current
< 0.50 Ampere
Frequency
50 ~ 60 Hz
Typical Power
Consumption
33 watts
Maximum
< 37 watts
Power Saving
< 2 watts
Power Cable Length
74.8 in (1.9 m); detachable
Mechanical
Dimensions
(H x W x D)
Unpacked with stand
20.1 x 16.6 x 10.3 in (51.1 x 42.2 x 26.2 cm)
Display Head only
14.3 x 16.6 x 2.3 in (36.2 x 42.2 x 5.9 cm)
Packaged
20.2 x 17.9 x 13.7 in (51.4 x 45.5 x 34.8 cm)
Weight
Unpacked
16.7 lb (7.6 kg)
Packaged
21.4 lb (9.7 kg)
Tilt Range
-3 to +20 degrees vertical tilt
Swivel Range
-180° to + 180°
Height Adjustable
Yes, range:5.1 in (13 cm)
Base and Stand
Detachable, attaches to monitor using HP Quick Release
Environmental
Temperature –
Operating
50° to 95° F (10° to 35° C) non-condensing
Temperature –
Non-operating
-4° to 140° F (-20° to 60° C)
Humidity – Operating
20% to 80% non-condensing
Humidity –
Non-operating
5% to 90%
Altitude – Operating
0 to 12,000 ft (0 to 3,658 m)
Altitude –
Non-operating
0 to 40,000 ft (0 to 12,100 m)
Environmental Data
Eco-Label
Certifications and
Declarations
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
ENERGY STAR®
IT ECO declaration
TCO 03
Energy Consumption
(in accordance with US
Energy Star test method)
AC Input Voltage at
100 VAC +/- 5 VAC, 50
Hz +/- 3 Hz
AC Input Voltage at
115 VAC +/- 5 VAC, 60
Hz +/- 3 Hz
AC Input Voltage at
230 VAC +/- 5 VAC, 50
Hz +/- 3 Hz
Normal Operation
31.2 watts
31 watts
30.7 watts
Sleep
2.65 watts 2.32 watts 2.45 watts
Off
0.58 watts 0.37 watts 0.40 watts
Heat Dissipation*
100 VAC, 50 Hz 115 VAC, 60 Hz 230 VAC, 50 Hz
Normal Operation
106.70 BTU/hr 106.02 BTU/hr 104.99 BTU/hr
Sleep
9.06 BTU/hr 7.93 BTU/hr 8.38 BTU/hr
Off
1.98 BTU/hr 1.27 BTU/hr 1.37 BTU/hr
*
Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
QuickSpecs
HP L1906i Flat Panel Monitor
Technical Specifications
DA - 12762 Worldwide QuickSpecs — Version 2 — 9.5.2007
Page 4
