Panel
Type
Active matrix, thin film transistor (TFT)
Viewable Image Area
(diagonal)
19 in (48.25 cm) maximum viewable
Screen Opening
(WxH)
14.9 x 12.0 in (38.0 x 30.5 cm)
Viewing Angle
(typical)
1
178 degrees horizontal/178 degrees vertical (10:1 minimum contrast
ratio)
Brightness
(typical)
1
300 nits (cd/m
2
)
Contrast Ratio
(typical)
1
1000:1 (typical)
Response Time
(typical)
1
6 ms (typical gray to gray)
2
Color Gamut
72%
Pixel Pitch
0.294 mm
Backlight Lamp Life
(to half brightness)
50K hours
Bezel Width
13 mm
Video/Other Inputs
Plug and Play
Yes (supports VESA DDC2B and DDC/CI; PC2001 compliant)
Self Powered USB 2.0
Hub
One upstream, four downstream ports (cable included)
Input Signal
Two DVI-I connectors (VGA analog or digital) with HDCP over digital
DVI
Input Impedance
75 ohms ± 2%
Sync Input
Separate sync (HSYNC/VSYNC); composite sync, Sync on Green
(activated through on-screen display)
Video Cable
One DVI-D to DVI-D, and 1 DVI-I to VGA cables
Video Cable Length
71 in (1.8 m)
Signal Interface/
Performance
Horizontal Frequency
24 to 83 kHz
Vertical Frequency
48 to 76 Hz
Native Resolution
1280 x 1024 @ 75 Hz analog
1280 x 1024 @ 60 Hz digital
Maximum Resolution
(Analog)
1280 x 1024 @ 75 Hz analog
Maximum Resolution
(Digital)
1280 x 1024 @ 75 Hz digital
Preset VESA Graphic
Modes
(non-interlaced)
640 x 480 @ 60 Hz, 72 Hz, 75 Hz
720 x 400 @ 70 Hz
800 x 600 @ 60 Hz, 72 Hz, 75 Hz
1024 x 768 @ 60 Hz, 70 Hz, 75 Hz
1280 x 1024 @ 60 Hz, 75 Hz
Preset MAC Mode
832 x 624 @ 75 Hz
1152 x 870 @75 Hz
Preset VGA Mode
640 x 480 @ 60 Hz, 72 Hz
Preset SUN Mode
1152 x 900 @ 76 Hz
Fail Safe Mode
Yes (limits out of range signal messages)
Maximum Pixel Clock
Speed
140 MHz
User Programmable
Modes
Yes, 15
Anti-Glare
Yes
QuickSpecs
HP LP1965 19-inch LCD Monitor
Technical Specifications
DA - 12620 Worldwide QuickSpecs — Version 9 — 5.22.2008
