Specifications
C-4 HP Uninterruptible Power System T2200 XR Models User Guide
Table C-4: Output Specifications
Characteristics
Configuration
Setting (VAC)
Available Nominal
Output Voltage
(VAC)
Available Nominal
Output Voltage
(VAC) on Battery
Voltage 100 100 110*
110 110 110
120 120 120
127 127 120
208 208 220*
220 220 220
230 230 230
240 240 240
Source of Power Regulation
Output
Tolerance
Utility power
(normal range)
-10% to +6% of nominal output voltage rating
(within the guidelines of the Computer Business
Equipment Manufacturers Association)
Battery power
±5% of nominal output voltage rating*
Feature Specification
Other Features On-line efficiency 95% nominal input voltage
Voltage wave shape Sine wave; equivalent to input online
Surge suppression High energy 6500 A peak
Noise filtering MOVs and line filter for normal and common
mode use
* +0% to -10% at low battery
Battery Specifications
Table C-5: Battery Specifications
Feature Specification
Type Sealed lead-acid; maintenance-free
Voltage 48 V Battery String
Charging HP recommends 24 hours to allow full charge
Less than 3 hours to 90 percent capacity at default nominal utility voltage and no load
