Top Products
Integrated Realtek
Integrated RealtekIntegrated Realtek
Integrated Realtek
RTL8103EL 10/100 Fast
RTL8103EL 10/100 FastRTL8103EL 10/100 Fast
RTL8103EL 10/100 Fast
Ethernet Controller
Ethernet ControllerEthernet Controller
Ethernet Controller
Controller
ControllerController
Controller
8101E
Memory
MemoryMemory
Memory
N/A
Data rates supported
Data rates supportedData rates supported
Data rates supported
2.5GHz data rate with X1 link width
Compliance
ComplianceCompliance
Compliance
IEEE802.3, IEEE 802.3u, IEEE 802.3ab
Bus architecture
Bus architectureBus architecture
Bus architecture
PCIexpress 1.1
Data transfer mode
Data transfer modeData transfer mode
Data transfer mode
Half/Full Duplex Operation
Hardware certifications
Hardware certificationsHardware certifications
Hardware certifications
MS NDIS5, IPv4, Ipv6, TCP, UDP
Power requirement
Power requirementPower requirement
Power requirement
100mbps (heavy traffic)
max.
TBD mW
10mbps (heavy traffic)
max.
TBD mW
S3 with Link
TBD mW
Link Down @S0
TBD mW
Link Down @S3/S5
TBD mW
Boot ROM support
Boot ROM supportBoot ROM support
Boot ROM support
EEPROM, 1Kb, 2Kb
Network transfer rate
Network transfer rateNetwork transfer rate
Network transfer rate
10/100Mbps over CAT.5
10Mbps over CAT.3
Dimensions
DimensionsDimensions
Dimensions
9mm x 9mm
Management capabilities
Management capabilitiesManagement capabilities
Management capabilities
ACPI rev 2.0, PM rev 1.1, ASPM v1.0a
Intel Gigabit CT Desktop
Intel Gigabit CT DesktopIntel Gigabit CT Desktop
Intel Gigabit CT Desktop
NIC
NICNIC
NIC
Connector
ConnectorConnector
Connector
RJ-45
Controller
ControllerController
Controller
Intel WG82574L Gigabit Ethernet Controller
Memory
MemoryMemory
Memory
Integrated Dual 48K configurable transmit receive FIFO Buffers
Data rates supported
Data rates supportedData rates supported
Data rates supported
10/100/1000 Mbps
Compliance
ComplianceCompliance
Compliance
IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,
802.3x flow control
Bus architecture
Bus architectureBus architecture
Bus architecture
PCI-E 1.0a
Data path width
Data path widthData path width
Data path width
X1, 250 MB/s, Bi-directional interface
Data transfer mode
Data transfer modeData transfer mode
Data transfer mode
Bus-master DMA
Hardware certifications
Hardware certificationsHardware certifications
Hardware certifications
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark
for European Union
Power requirement
Power requirementPower requirement
Power requirement
Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Boot ROM support
Boot ROM supportBoot ROM support
Boot ROM support
Yes
Network transfer rate
Network transfer rateNetwork transfer rate
Network transfer rate
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Environmental
EnvironmentalEnvironmental
Environmental
Operating temperature
Operating temperatureOperating temperature
Operating temperature
32° to 131°F (0° to 55° C)
Operating humidity
Operating humidityOperating humidity
Operating humidity
85% at 131° F (55° C)
Dimensions
DimensionsDimensions
Dimensions
4.75 x 2.25 x 0.8 in (12.1 x 5.7 x 2.0 cm)
QuickSpecs
Compaq 500B Microtower PC
Compaq 500B Microtower PCCompaq 500B Microtower PC
Compaq 500B Microtower PC
Technical Specifications - Communications
DA - 13418 North America — Version 2 — October 30, 2009
Page 16
