Technical Specifications
B–4 User’s Guide
Preset Video and High-Definition Modes
The monitor automatically recognizes many preset video input modes that will appear properly sized and centered
on the screen.
Factory Preset Video Input Modes, w1858
Preset Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
1 640 x 480 31.4 59.9
2 720 x 400 31.5 70.0
3 800 x 600 37.9 60.3
4 832 x 624 49.7 74.5
5 1024 x 768 48.4 60.0
6 1024 x 768 60.0 75.0
7 1152 x 870 68.7 75.1
8 1152 x 900 61.8 65.9
9 1280 x 720 44.7 59.9
10 1280 x 768 47.4 60.0
11 1280 x 960 60.0 60.0
12 1280 x 1024 63.9 60.0
13 1280 x 1024 79.9 75.0
14 1360 x 768 47.7 60.0
15 1366 x 768 47.7 59.8
Factory Preset Video Input Modes, w2228
Preset Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
1 640 x 480 31.4 59.9
2 640 x 480 37.5 75.0
3 720 x 400 31.5 70.0
4 800 x 600 37.9 60.3
5 800 x 600 46.9 75.0
6 832 x 624 49.7 74.5
7 1024 x 768 48.4 60.0
8 1024 x 768 60.0 75.0
9 1152 x 720 44.8 60.0
10 1152 x 870 68.7 75.1
11 1152 x 900 61.8 65.9
12 1280 x 768 47.4 60.0
13 1280 x 960 60.0 60.0
