Chapter2 Installation 37
Compact Flash Connector (CN22)
Pin Signal Pin Signal
1 GND 26 GND
2DATA3 27DATA11
3 DATA4 28 DATA12
4 DATA5 29 DATA13
5 DATA6 30 DATA14
6 DATA7 31 DATA15
7 CS#1 32 CS#3
8 GND 33 GND
9 GND 34 IO READ
10 GND 35 IO WRITE
11 GND 36 +5V
12 GND 37 IRQ15
13 +5V 38 +5V
14 GND 39 CSEL
15 GND 40 N.C.
16 GND 41 IDE RESET
17 GND 42 IO READY
18 ADDR2 43 N.C.
19 ADDR1 44 +5V
20 ADDR0 45 DASP
21 DATA0 46 DIAG
22 DATA 1 47 DATA8
23 DATA 2 48 DATA9
24 N.C. 49 DATA10
25 GND 50 GND
Compact Flash Connector (CN22)
