Special instructions for Ordering of Processors:
The NSW1U supports a range of processor speeds from 1.6 GHz to 3.0 GHz.
Ordering details for the CPU for use in NSW1U are listed below, and includes
both Tray (for OEMs) and Boxed (Retail channel) processors.
Dual-Core Intel® Xeon® Processors Supported by NSW1U:
Processor
Number
Speed FSB TDP Boxed Processor
Product Code
Tray Processor
Product Code
5160 3.00 GHz 1333 MHz 80W BX805565160A HH80556KJ0804M
5150 2.66 GHz 1333 MHz 65W BX805565150A HH80556KJ0674M
5140 2.33 GHz 1333 MHz 65W BX805565140A HH80556KJ0534M
5130 2.00 GHz 1333 MHz 65W BX805565130A HH80556KJ0414M
5120 1.86 GHz 1066 MHz 65W BX805565120A HH80556KH0364M
5110 1.6 GHz 1066 MHz 65W BX805565110A HH80556KH0254M
LV 5148 2.33 GHz 1333 MHz 40W BX805565148A HH80556JJ0534M
LV 5128 1.86 GHz 1066 MHz 40W N/A HH80556JH0364M
Notes:
Although all of the above processors are tested and supported, Intel
recommends the use of the following processors from Intel’s Infrastructure
Processor Division (IPD) for long availability and support.
o 5140 (2.33 GHz, 1333MHz FSB, 65W)
o 5130 (2.00 GHz, 1333MHz FSB, 65W)
o LV 5148 (2.33 GHz, 1333MHz FSB, 40W)
o LV 5128 (1.86 GHz, 1066MHz FSB, 40W)
The boxed CPUs listed above include a Active/Passive Heatsink Kit.
Simply remove the fan from the Kit, and install into the system as shown
in the product documentation.
For Tray CPUs, you will need to procure a Heatsink Kit (TMWHSNK01W)
and thermal grease for each processor.
Note that CPU product codes can change, and that the above is a snapshot
current as of 5/17/2007. Please consult with your Intel representative for SSpec
or MM# which may be needed for ordering the CPU. Any differences in
functionality is reported in Monthly Specification updates available on
http://developer.intel.com
.
