Konica Minolta FM01FD02B All in One Printer User Manual



Type
Semi-console model with fixed platen
Process
Electrostatic laser method
User Operation
Touch sensitive,tilt-capable display with detailed user
instructions,Check/Help Mode,Proof Copy, Power Saver
Copies/prints per minute
28 pages (A4),15 pages (A3)
FCOT
Approx. 4.2 seconds (A4,platen, no AES)
Warm-up time
Approx. 19 seconds
Original Processing/Feeding
Face-up, 1-to-N
Resolution
Scanning/printing 600 x 600 dpi
Image Memory
64 MB standard,320 MB max. (ie.64 MB + 256 MB)
Network Card
Standard; 10BaseT/100BaseTX
Copy/Print Quantity Selection
Up to 999
Exposure
Automatic or Manual,2 user sets
Magnification
Fixed Ratios:1:1; Reduction: 0.71/0.82/0.86
Enlargement:1.15/1.22/1.41;special ratios (user setting)
Zoom 25% – 400% (DF: 50 – 400%),
adjustable in 1% increments,Bi-directional zoom
Paper Sizes
A5 – A3
Paper Supply
Two front-loading universal trays for max. 500 sheets
each;multi-sheet bypass for 50 sheets
Paper Weight
60 – 90g/m
2
(from tray); special paper 50 – 130g/m
2
(from bypass)
Duplexing (standard)
Direct unlimited duplexing,A5 – A3;60 – 105 g/m
2
Special Functions
Network Scanner (scan to e-mail/ftp),Job Reservation (5),
Memory Copy,Booklet Mode, Image Rotation,Electronic
Sorting (without finisher),Image Repeat,Image Insert,
2-in1/4-in1/8-in1,Density Shift, Photo/Text/Increase
Contrast, Non-Image Area Erase,Auto Layout,Reverse
Copying, Chapter/Cover & Sheet Insertion,OHP-Inter-
leave,Image Shift,Reduce & Shift,Book Copy, Frame & Fold
Erasure, Mixed Originals (with DF), Stamp,Watermark,
One-Time Overlay, Job Memory (15),Copy Interrupt,
APS,ATS,Auto Reset,Auto Shut Off, Power Saving,
Self Diagnostic System, EKC (256 codes),Weekly Timer,
List Report,Fail Safe Function,KRDS,customisable
Application Screen (key operator), etc.
Power Supply/Consumption
220–240V,50Hz/max.1500 Watt (system)
Tec hni cal S pe cif icat io ns Kon ica Mi no lta 7 228
Dimensions (W x D x H)
595 x 655 x 1134 mm (main body with DF)
Weight
approx. 83 kg (main body with DF)
Optional Accessories
Option Description
CV-109 Platen Cover
DF-320 e-RDH for max. 80 sheets,A5 – A3,
35 – 130 g/m
2
, 45 OPM simplex/34
OPM duplex (at 600 dpi); up to 65
OPM simplex at 300 dpi
DB-211 Drawer base unit with two front-
loading universal trays for max. 500
sheets each,60 – 90g/m
2
DB-411 Drawer base unit for max. 1,500
sheets,A4, 60 – 90g/m
2
LT-203 LCT for max.2,000 sheets,A4,
60 – 90g/m
2
DK-110 Basic pedestal
ET-101 Exit tray for 100 sheets plus 2 side
covers
IT-101 Inner output tray (upper max. 50,
lower max.100 sheets)
FS-113 2-tray finisher for max.3,250 sheets,
A5 – A3, 50 – 130g/m
2
, 4 position
stapling/4 hole European punching
RU-101 Relay unit for FS-113
FS-114 2-tray finisher for max.1,200 sheets,
A5 – A3, 50 – 130g/m
2
, 50 sheet
multi-position stapling
SK-114 Saddle stitch kit for booklets for
FS-114,A3 – A4, 60 – 90g/m
2
,
2 – 15 sheet booklets
PK-114 4 hole punch kit for FS-114,
A3 – B5, 60 – 163g/m
2
BK-114 Bin kit for FS-114,A3 – A5,
50 – 130g/m
2
,max.1 can be installed
SK-101 Stapler cartridge kit for FS-114
Memory Extension 64 MB, 128 MB, 256 MB
HD-103A 20 GB
Printer Option IP-424
Type
Embedded
Print Speed
28 ppm
Resolution
600 x 600 dpi
Paper Size
A5 – A3
PDL
PCL5e/6 compatible, PS3 (optional)
CPU
NS Geode GX-1,300 MHz
Host Interface
PCI
Printer Drivers
Win95/98/Me/NT4.0/2000,XP,Mac OS (PS3 only)
Network Protocols
TCP/IP,LPD/LPR,IPX/SPX,IPP, FTPserver, FTPclient,
SNMPclient,HTTP, SNMP,EtherTalk
Standard Memory
128 MB standard/max.
Special Functions
Print Quantity Setting,Orientation,Paper Tray selection,
Output Paper Size selection,Zoom, Exit Tray selection,
Sort/Staple/Punch (with finisher),Alternate Sort (without
finisher),Duplex, Password Printing (w/HD),Overlay,
Booklet,Front/Back Cover,N-up,Watermark,Smoothing,
OHP,PC-fax (with optional FK-103),Toner Save, etc.
Network Card
standard with main body (10baseT/100baseTX)
PS-346
Optional PostScript up-grade (PS3)
CF-101
Compact Flash Card for font download (128 MB)
Cluster Printing
KPPM (optional software)
Fax Option FK-103
Compatibility
SuperG3
Modem Speed
33.6 Kbps
Original Scanning Speed
approx. 2 seconds
Transmission Speed
approx. 2 seconds
Transmission Resolution
max.400 x 400 dpi
Scanning Resolution
max.16pels/mmx15.4lines/mm
Half Tones
256 grey scales
Coding
MH,MR, MMR,JBIG
Memory
16 MB
Original/Recording Size
max.A3
One-Touch Dials
40
Abrreviated Dials
500
Group Dials
20
Special Functions
Broadcasting Transmission,Quick Memory Transmission
(fax while scan),Rotational Transmission/Receiving,Book
Copy Transmission, 2-in-1 Transmission/Recording, Duplex
Recording,Remote Multi-Printing,PC-Fax with IP-424,etc.
The availability of the special functions listed above
depends on the optional accessories installed on
Konica Minolta 7228.
All indications regarding paper,original and output
capacities refer to the max. capacity based on standard
80 g/m
2
paper.
Technical Specifications subject to change without notice!
Latest valid technical specifications can be obtained from
your Konica Minolta partner.Status:03/2004.
