WIR-97020B page 2 of 2
760A/761APH
GNONC BS
TD
NOTE 1
NOTE 1: With terminal “G” grounded, the time delay operates only on start; after the initial
time delay, the shut-down circuit is operated immediately when SWICHGAGE
®
contact operates.
With terminal “G” not grounded, the time delay operates both on start and stop.
B
+
GRDSIG
_
+
Ignition 
Coil
Distributor
Normally Open
Relay with 
Flyback Diode
Flyback
Diode
Flyback
Diode
Flyback
Diode
Rack Pull 
Solenoid
(RP2300 
Series shown)
Tachometer
Hourmeter
Voltmeter
20T
Temperature
20P
Pressure
Ammeter
Battery
_
+
_
+
_
+
ST
ACC
IGN
BAT
Start Switch
Alternator
To Magnetic Sensor,
Alternator “Tach”
Terminal, or
Signal Generator
B
+
Energized
to Run
PB128S Stop Switch
Starter
S
B
Exciter
R
Fuel
Valve
Typical Wiring Diagram with 760A and 761APH
G NO
R
NC
SW1 SW2
B
518PH
Jumper
*
B
+
GRDSIG
_
+
Ignition coil
Distributor
Fuel Valve
Rack Pull Solenoid (RP2300 Series shown)
Tachometer
Hourmeter
CLOSEDLOOP™ Wiring
*
Voltmeter
20T-F
Temperature
20P-F
Pressure
Ammeter
Battery
_
+
_
+
_
+
ST
ACC
IGN
BAT
Start Switch
Alternator
To Magnetic Sensor,
Alternator “Tach”
Terminal, or
Signal Generator
B
+
Energized
to Run
Starter
S
B
Exciter
PB128S Stop Switch
*
Jumper is to be removed when connecting a CLOSEDLOOP™ circuit.
**
Normally Opened terminal is available on the 518APH & 518E models.
**
Typical Wiring with 518PH TATTLETALE
®
