Specifications
Monitor AccuSync
™
125F Notes
Specifications Monitor
Picture Tube Diagonal: 22 inch/55 cm 90° deflection, 0.24 mm grille pitch,
Viewable Image Size: 20 inch/51cm medium short persistence phosphor,
Radius: 50000 mm aperture grille CRT, G-WARAS coating
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 30 kHz to 96 kHz Automatically
Range Vertical: 50 Hz to 160 Hz Automatically
Resolutions Supported 640 x 480 @ 50 to 160 Hz
Some systems may not support
Resolution based on
horizontal and
720 x 400 @ 50 to 160 Hz
all modes listed.
vertical frequencies only
800 x 600 @ 50 to 152 Hz
1024 x 768 @ 50 to 120 Hz
1152 x 870 @ 50 to 105 Hz
1280 x 1024 @ 50 to 89 Hz.........................NEC cites recommended resolution at
1600 x 1200 @ 50 to 76 Hz 85 Hz for optimal display performance.
Active Display Area Horizontal:
396 mm/15.6 inches Dependent upon signal timing used,
(Factory Setting) Vertical:
297 mm/11.7 inches and does not
include border area.
Active Display Area
406 mm/16.0 inches Dependent upon signal timing used,
(Full Scan)
305 mm/12.0 inches and does not
include border area.
Power Supply
AC 100 – 120 V / 220 - 240 V, 50/60 Hz
Current Rating 1.3A @ 100
–
120 V / 0.6A @ 220 - 240 V
Dimensions
495 mm (W) x 493.5 mm (H) x 473 mm (D)
19.5 inches (W) x 19.4 inches (H) x 18.6 inches (D)
Weight 29.7 kg
65.5 lbs
Environmental Considerations
Operating Temperature: +10°C to +35°C/+50°F to +90°F
Humidity: 30% to 80%
Altitude: 3,000 m/10,000 Feet
Storage Temperature: -20°C to +60°C/-4°F to +140°F
Humidity: 10% to 90%
Altitude: 15,000 m/50,000 Feet
NOTE: Technical specifications are subject to change without notice.
