Power
Cord
Power Outlet
Quick Start cont.Start
5
Figure D.1
Figure C.1
RESET DVI/D-SUBPROCEEDEXIT
MultiSync
Power Button
DVI/D-SUB
If your computer is equipped with USB and uses the Windows
®
98 operating system and
you want to operate the monitor’s user controls using your system, you can install USB
support by using the following procedure. To attach the USB port on your MultiSync
®
FP1350X
™
monitor to a USB port on your system:
1. Using the supplied USB cable, connect the USB Series B connector end to the USB
upstream port on the monitor (Figure 1).
2. Connect the other end of the supplied cable to the USB downstream port on the
computer (or to a USB Hub attached to the computer) (Figure 1).
3. Install the supplied Monitor Control Software.
Figure 1
USB upstream port
USB Series B
connector end
USB downstream port
