NEC JC-1736VMB Computer Monitor User Manual



Active Display
Area*** (Factory
Setting)
Horizontal 270 mm (A
500)
306 mm (A
700)
Vertical 202 mm (A
500)
230 mm (A
700
)
Active Display
Area*** (Full
Scan)
Horizontal 280 mm (A
500)
316 mm (A
700)
Vertical 210 mm (A
500)
237 mm (A
700)
Rated Voltage AC 220-240 V 50/60 Hz
Rated Current 0.9 A (A
500) 0.8 A (A700)
Dimensions W x H x D 372 x 402 x 402 mm (A
500)
403 x 427 x 440 mm (A
700)
Weight 15.1 kg (A
500) 18.5 kg (A700)
Environmental
Considerations
Operating Temperature 0° C to + 35° C
Humidity 30% to 80%
Storage Temperature -20° C to + 60° C
Humidity 10% to 90%
* NEC cites recommend resolutions for optimal display performance.
** Maximum resolution based on horizontal and vertical frequencies only.
*** Active display area is dependent upon the signal timing.
Technical specifications are subject to change without notice.
Specifications E - 15
