Monitor MultiSync
®
LCD1860NX
Notes
Specifications Monitor
LCD Module Diagonal : 18.1 inch Active matrix; thin film transistor (TFT)
Viewable Image Size : 18.1 inch liquid crystal display (LCD); 0.28 mm dot
Native Resolution (Pixel Count) : 1280 x 1024 pitch; 200cd/m
2
white luminence;
350:1 contrast ratio, typical
Input Signal Video : ANALOG 0.7 Vp-p/75 Ohms Digital Input: DVI
Sync : Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Display Colors Analog input : 16,777,216 Depends on display card used.
Maximum Left/Right : 70°/70°
Viewing Angles Up/Down : 70°/70°
Synchronization Horizontal : 31.5 kHz to 81.1 kHz (Analog) Automatically
Range 31.5 kHz to 80.0 kHz (Digital) Automatically
Vertical : 56.0 Hz to 85.0 Hz Automatically
Resolutions Supported 720 x 400*
1
:VGA text
Some systems may not support all modes listed.
640 x 480*
1
@ 60 Hz to 85 Hz
800 x 600*
1
@ 56 Hz to 85 Hz
832 x 624*
1
@ 75 Hz
1024 x 768 @ 60 Hz to 85 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60 Hz to 75 Hz (Analog)
.......
NEC-Mitsubishi Electronics Display cites
1280 x 1024 @ 60 Hz (Digital)
recommended resolution at 60 Hz for
optimal display performance.
Active Display Area Horizontal : 359 mm/14.1 inches
Vertical : 287 mm/11.3 inches
Power Supply AC100 - 120V/220-250V Hz
Current Rating 0.8 0.4A
Dimensions 398 mm (W) x 402.8 mm (H) x 200 mm (D)
15.7 inches (W) x 15.9 inches (H) x 7.9 inches (D)
Weight 7.3 kg
16.1 lbs
Environmental Considerations
Operating Temperature : 5°C to 35°C/41°F to 95°F
Humidity : 30% to 80%
Feet : 0 to 10,000 Feet
Storage Temperature : -10°C to 60°C/14°F to 140°F
Humidity : 10% to 85%
Feet : 0 to 30,000 Feet
*
1
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
