NEC LCD1904M Computer Monitor User Manual



Specifications –continued
Monitor LCD
Specifications Monitor
LCD Module Diagonal: 17.0 inch Active matrix; thin film transistor (TFT)
Viewable Image Size: 17.0 inch liquid crystal display (LCD); 0.264 mm dot
Native Resolution (Pixel Count): 1280 x 1024 pitch.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync TTL Level (Positive/Negative)
Horizontal sync Positive/Negative
Vertical sync Positive/Negative
Display Colors Analog input: 16,194,277 Depending on display card used.
Synchronization Horizontal: 31.5 kHz to 81.1 kHz Automatically
Range Vertical: 55 Hz to 76 Hz Automatically
Resolutions Supported 720 x 400*
1
: VGA text
Some systems may not support
640 x 480*
1
at 60 Hz to 75 Hz
all modes listed.
800 x 600*
1
at 56 Hz to 75 Hz
832 x 624*
1
at 75 Hz
1024 x 768*
1
at 60 Hz to 75 Hz
1152 x 864*
1
at 70 Hz
1152 x 870*
1
at 75 Hz
1280 x 960
*
1
at 60 Hz to 75 Hz
recommended resolution at 60 Hz for
1280 x 1024 at 60 Hz to 75 Hz................
optimal display performance.
Active Display Area Horizontal :
338 mm/13.3 inches
Vertical :
270.3 mm/10.6 inches
Power Supply
100
-240 V
~ 50/60 Hz
Current Rating 0.6 - 0.4 A/100-240V
Dimensions
375.4 mm (W) x 389 mm (H) x 180 mm (D)
14.8 inches (W) x 15.3 inches (H) x 7.1 inches (D)
Weight 4.6 kg
10.1 lbs
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Humidity: 10% to 80%
Feet: 0 to 10,000 Feet
Storage Temperature: -10°C to +60°C/14°F to 140°F
Humidity: 10% to 85%
Feet: 0 to 40,000 Feet
*
1
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
NEC DISPLAY SOLUTIONS
31
Notes
MaximumLeft/right:70°/70° (CR>10)
Viewing AnglesUp/Down:65°/60° (CR>10)
