NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
Ambix and OSD are registered trademarks, and
AccuSync, ECO Mode, NaViSet, No Touch Auto
Adjust and Rapid Response are trademarks of NEC
Display Solutions. All other brand or product names
are trademarks or registered trademarks of their
respective holders.
Product specifications subject to change. 6/08 ver. 2.
©
2008 NEC Display Solutions of America, Inc.
Model
Display
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Input
Resolutions Supported
Native Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Dimensions (W x H x D)
Net (with stand)
Net (without stand)
Weight
Net (with stand)
Net (without stand)
VESA Hole Configuration
Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
AccuSync LCD224WXM
22” widescreen
0.282
90 @ native resolution
300 cd/m
2
900:1
176° Vert., 176° Hor. (88U/88D/88L/88R)
(CR>5)
Rapid Response (5ms)
More than 16 million
31.5 - 81.1 KHz (Analog/Digital)
56 - 76 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (Positive/Negative)
DVI-D and VGA 15-pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 768 @ 60-75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-75 Hz
1360 x 768 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
1400 x 1050 @ 60-75 Hz
1680 x 1050 @ 60-75 Hz
1680 x 1050 @ 60-75 Hz
Thin-frame (bezel), tilt, integrated speakers,
headphone jack, No Touch Auto Adjust,
cable management, ECO Mode, digital
smoothing, digital controls, AccuColor
color control, sRGB, On Screen Display user
controls, NaViSet software, DDC/CI, Plug
and Play (VESA DDC2B), VESA DPMS power
management, ISO 13406-2 Class II, Energy
Star Tier 2, Windows Vista certification
Yes*
AC 100-120V/AC 220-240V
50W
<2W
19.9 x 15.4 x 8.7 in./505.2 x 390.9 x 221.8mm
19.9 x 13.5 x 2.6 in./505.2 x 342.9 x 65.2mm
11.5 lbs. / 5.2 kg
10.6 lbs. / 4.8 kg
100 x 100mm
5-35° C / 41-95° F
30 - 80%
4572m / 15,000 ft.
-10 - 60° C / 14-140° F
10 - 85%
12,192m / 40,000 ft.
3 year parts and labor, including backlight
M - F (7am - 7pm CST)
AccuSync LCD194WXM
19” widescreen
0.284
90 @ native resolution
300 cd/m
2
1000:1
176° Vert., 176° Hor. (88U/88D/88L/88R)
(CR>5)
Rapid Response (5ms)
More than 16 million
31.5 - 81.1 KHz (Analog/Digital)
56 - 76 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (Positive/Negative)
DVI-D and VGA 15-pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 768 @ 60-75 Hz
1360 x 768 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
Thin-frame (bezel), tilt, integrated speakers,
headphone jack, No Touch Auto Adjust,
cable management, ECO Mode, digital
smoothing, digital controls, AccuColor
color control, sRGB, On Screen Display user
controls, NaViSet software, DDC/CI, Plug
and Play (VESA DDC2B), VESA DPMS power
management, ISO 13406-2 Class II, Energy
Star Tier 2, Windows Vista certification
Yes*
AC 100-120V/AC 220-240V
41W
<2W
17.3 x 13.7 x 8.3 in./439.4 x 347.1 x 209.8mm
17.3 x 11.8 x 2.5 in./439.4 x 299.8 x 64.6mm
10.1 lbs. / 4.6 kg
9.5 lbs. / 4.3 kg
100 x 100mm
5-35° C / 41-95° F
30 - 80%
4572m / 15,000 ft.
-10 - 60° C / 14-140° F
10 - 85%
12,192m / 40,000 ft.
3 year parts and labor, including backlight
M - F (7am - 7pm CST)
AccuSync LCD174WXM
17” widescreen
0.255mm
100 @ native resolution
250 cd/m
2
800:1
170° Vert., 176° Hor. (85U/85D/88L/88R)
(CR>5)
Rapid Response (8ms)
More than 16 million
31.5 - 81.1 KHz (Analog/Digital)
56 - 75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (Positive/Negative)
DVI-D and VGA 15-pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 768 @ 60-75 Hz
1360 x 768 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
1440 x 900 @ 60-75 Hz
Thin-frame (bezel), tilt, integrated speakers,
headphone jack, No Touch Auto Adjust,
cable management, ECO Mode, digital
smoothing, digital controls, AccuColor
color control, sRGB, On Screen Display user
controls, NaViSet software, DDC/CI, Plug
and Play (VESA DDC2B), VESA DPMS power
management, ISO 13406-2 Class II, Energy
Star Tier 2, Windows Vista certification
Yes*
AC 100-120V/AC 220-240V
25W
<2W
15.7 x 12.7 x 8.3 in. / 400 x 323.5 x 209.8mm
15.7 x 10.8 x 2.5 in. / 400 x 275.5 x 63mm
8.2 lbs. / 3.7 kg
7.5 lbs. / 3.4 kg
100 x 100mm
5-35° C / 41-95° F
30 - 80%
3048m / 10,000 ft.
-10 - 60° C / 14-140° F
10 - 85%
12,192m / 40,000 ft.
3 year parts and labor, including backlight
M - F (7am - 7pm CST)
* Only cabinet space available for wiring. No power supply.
