Monitor RDF225WG Notes
Specifications Monitor
Picture Tube Diagonal: 22 inch/550mm 90° deflection, 0.24 mm grille pitch,
Viewable Image Size: 20 inch/508mm wide color gamut phosphor, aperture
Radius: 50,000 mm grille CRT, G-WARAS coating
Luminanace (peak) 100cd/m
2
@ 9300K
80cd/m
2
@ 6500K
70cd/m
2
@ 5000K
Color Coordinates Red: x=0.650, y=0.321
Green: x=0.208, y=0.690 – long phosphor persistance time
Blue: x=0.151, y=0.070
Color Gamut 97.6% of Adobe RGB
93.3% of NTSC
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Sync on Green video (Positive) 0.7 Vp-p and sync
Negative 0.3 Vp-p
Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 30 kHz to 140 kHz Automatically
Range Vertical: 50 Hz to 160 Hz Automatically
Resolutions Supported 640 x 480 @ 50 to 160 Hz
Some systems may not support
Resolution based on
horizontal and
800 x 600 @ 50 to 160 Hz
all modes listed.
vertical frequencies only
1024 x 768 @ 50 to 160 Hz
1280 x 1024 @ 50 to 127 Hz
1600 x 1200 @ 50 to 109 Hz
1800 x 1350 @ 50 to 98 Hz
1800 x 1440 @ 50 to 92 Hz
1856 x 1392 @ 50 to 95 Hz
2048 x 1536 @ 50 to 86 Hz
Active Display Area Horizontal:
396 mm/15.6 inches Dependent upon signal timing used,
(Factory Setting) Vertical:
297 mm/11.7 inches and does not
include border area.
Active Display Area
406 mm/16.0 inches Dependent upon signal timing used,
(Full Scan)
304.6 mm/12.0 inches and does not
include border area.
Power Supply
AC 100 – 240 V/220-240V, 50-60 Hz
Current Rating 1.35A @ 100-240 V/0.65A @ 220-240V
Dimensions
495 mm (W) x 486 mm (H) x 477 mm (D)
19.5 inches (W) x 19.1 inches (H) x 18.8 inches (D)
Weight 29.3 kg
64.6 lbs
Environmental Considerations
Operating Temperature: +5°C to +35°C / +41°F to +90°F
Humidity: 10% to 90%
Feet: 0 to 10,000 Feet
Storage Temperature: -20°C to +60°C / -4°F to +140°F
Humidity: 10% to 90%
Feet: 0 to 50,000 Feet
NOTE: Technical specifications are subject to change without notice.
Specifications
