Controls
OSM
™
(On-Screen Manager) control buttons on the front of the monitor function
as follows:
SELECT Enters and exits the OSM menu.
CONTROL –/+ Selects one of the controls and increases or decreases the
adjustment.
/ Moves the highted area / to select control.
Adjusts the overall image and background screen brightness.
Adjusts the image brightness in relation to the background.
Color Preset: Select from 9300K or 6500K color temperature.
Color Temperature: Increases or decreases the color temperature.
RED Red Color Contrast: Adjust the red contrast of the display
GREEN Green Color Contrast: Adjust the green contrast of the display.
BLUE Blue Color Contrast: Adjust the blue contrast of the display.
Moves the image horizontally (left or right).
Moves the image vertically (up or down).
Increases or decreases the horizontal size of the image.
Increases or decreases the vertical size of the image.
Increases or decreases the curvature of the sides either inward or
outward.
Decreases or increases the curvature left or right.
Increases or decreases the top of the screen to be the same as
the bottom.
Increases or decreases the tilt of the sides either to the left or right.
