Monitor MultiSync
®
E1100+
™
Notes
Specifications Monitor
Picture Tube Diagonal: 53 cm/21 inch 90° deflection, 0.24 mm horizontal pitch,
Viewable Image Size: 50.2 cm/19.8 inch (0.28 mm diagonal trio dot pitch)
Radius: 1730 mm medium short persistence phosphor,
multi-layered, anti-static screen coating,
semi-tint screen, Invar Shadow Mask and
OptiClear
®
screen surface.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Display Colors Analog input: Unlimited number of Colors Depends on display card used.
Synchronization Horizontal: 31 kHz to 96 kHz Automatically
Range Vertical: 55 Hz to 160 Hz Automatically
Resolutions Supported 640 x 480 @ 60 to 160 Hz
Some systems may not support
Resolution based on
horizontal and
800 x 600 @ 55 to 152 Hz
all modes listed.
vertical frequencies only
832 x 624 @ 55 to 144 Hz
1024 x 768 @ 55 to 119 Hz
1152 x 870 @ 55 to 105 Hz
1280 x 1024 @ 55 to 89 Hz .....................
NEC cites recommended resolution at
1600 x 1200 @ 55 to 77 Hz
85 Hz for optimal display performance
Active Display Area Horizontal:
390 mm/15.4 inches Dependent upon signal timing used,
(Factory Setting) Vertical:
293 mm/11.5 inches and does not
include border area.
Active Display Area
402 mm/15.8 inches Dependent upon signal timing used,
(Full Scan)
301 mm/11.9 inches and does not
include border area.
Power Supply
AC 100 – 120 V/220 - 240 V@, 50/60 Hz
Current Rating 2.1A @ 100
–
120 V/1.4A@ 220-240 V
Dimensions
509 mm (W) x 519 mm (H) x 525 mm (D)
20.0 inches (W) x 20.4 inches (H) x 20.7 inches (D)
Weight 31.0 kg
68.3 lbs
Environmental Considerations
Operating Temperature: 0°C to +35°C
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
Storage Temperature: -20°C to +60°C
Humidity: 10% to 90%
Feet: 0 to 45,000 Feet
NOTE: Technical specifications are subject to change without notice.
