NEC MultiSync FP950 Computer Monitor User Manual



OSM TURN OFF: The OSM menu will stay on as long as it is in use. In
the OSM Turn Off sub-menu, you can select how long the monitor waits
after the last touch of a button to shut off the OSM menu. The preset
choices are 10, 20, 30, 60, 120 seconds.
OSM LOCK OUT: This control completely locks out access to all OSM
functions except brightness and contrast controls. When attempting to
activate OSM while in the lockout mode, a screen will appear indicating
that OSM controls are locked out. To activate the OSM Lockout function,
press PROCEED, then press “” and hold down simultaneously. To
de-activate the OSM Lockout, press PROCEED, then press “” and hold
down simultaneously.
IPM System Off Mode:
ENABLE: The IPM works normally, all stages
of the energy saving are used.
DISABLE: The OFF MODE of the IPM is not
used.
NOTE: For standard computers and display cards you should keep
the factory setting ENABLE.
EDGELOCK CONTROL: Operating your monitor at a non-standard
timing may cause images to appear darker than normal or have color
distortion. Use of the EdgeLock control will adjust images to their normal
state.
REFRESH NOTIFIER: A message will advise you if the refresh rate of the
signal being applied to the monitor by the computer is too low. For
further information, please refer to your display card or system manual.
Factory setting is OFF.
z Information
Provides you with additional information which includes the following:
DISPLAY MODE: Indicates the current mode and frequency setting of the
monitor.
FITNESS TIPS: The Fitness Tips provide you with helpful reminders to
periodically rest your eyes. You may select how frequently the reminders
are displayed based upon your individual needs. Select an interval from
15, 30, 45, 60, 90 or 120 minutes for the tips to appear. When the tips
appear, follow the advice of the tips and press EXIT to clear.
MONITOR INFO: Indicates the model number and the serial number.
E-9
