NEC LCD92V Computer Monitor User Manual


  Open as PDF
of 2

Model
Display:
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range:
Horizontal
Vertical
Input Signal:
Video
Sync
Input
Resolutions Supported
Native Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical):
On
Power Savings Mode
Dimensions (W x H x D):
Net (with stand)
Net (without stand)
Weight
Net (with stand)
Net (without stand)
VESA Hole Configuration Specifications
Environmental Conditions:
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
NEC AccuSync LCD Series Specifications
500 Park Boulevard, Suite 1100
Itasca, Illinois 60143
866-NEC-MORE
www.necdisplay.com
NEC Display Solutions
AccuColor, OSM and XtraView are registered trademarks and AccuSync, NaViSet,
Rapid Response, LCD52V, LCD52VM, LCD72V, LCD72VM, LCD92V and LCD200VX are
trademarks of NEC Display Solutions. All other brand or product names are
trademarks or registered trademarks of their respective holders. Product
specifications subject to change.
©2005 NEC Display Solutions of America, Inc. All rights reserved.
Item No. ASLCD-1 3/05 ver.7.
AccuSync LCD52VM
15"
0.297mm
86 @ native resolution
250 cd/m
2
400:1
110° Vert., 140° Hor.
(55U/55D/70L/70R)
Rapid Response (25ms)
More than 16 million
31.5-60 kHz
56-75 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
15-pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1024 x 768 @ 75 Hz
Bezel-integrated speakers,
NaViSet software, digital
smoothing, digital controls,
user (OSM) controls, Plug and
Play (VESA DDC2B & 2Bi),
AccuColor color control,
DDC/CI, VESA DPMS power
management, ISO 13406-2
Class II, cable management
Designed for integration
100-240V @ 50/60 Hz
23W
<2W
13.6 x 13.9 x 6.5 in. /
344.6 x 352.7 x 165mm
13.6 x 11.2 x 2.3 in. /
344.6 x 285 x 57.5mm
7.3 lbs. / 3.3 kg
6.4 lbs. / 2.9 kg
75 x 75mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours / 7 days
AccuSync LCD72V
17"
0.264mm
96 @ native resolution
250 cd/m
2
450:1
145° Vert., 160° Hor.
(75U/70D/80L/80R)
Rapid Response (16ms)
More than 16 million
31.5-81 kHz
56-75 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
15-pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60 Hz
NaViSet software, digital
smoothing, digital controls,
user (OSM) controls,Plug
and Play (VESA DDC & 2Bi),
AccuColor color control,
DDC/CI, VESA DPMS power
management, ISO 13406-2
Class II, cable management
Designed for integration
100-240V @ 50/60Hz
30W
<2W
14.8 x 15.3 x 7.1 in. /
375.4 x 389 x 180mm
14.8 x 12.9 x 2.4 in. /
375.4 x 326.5 x 61mm
10.1 lbs. / 4.6 kg
9.3 lbs. / 4.2 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours/7 days
AccuSync LCD92V
19"
0.294mm
86 @ native resolution
250 cd/m
2
450:1
160° Vert., 160° Hor.
(80U/80D/80L/80R)
Rapid Response (16ms)
More than 16 million
31.5-81 kHz
56-75 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
15-pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60 Hz
NaViSet software, XtraView
wide-angle viewing, user
(OSM) controls,Plug and Play
(VESA DDC2B), AccuColor
color control, DDC/CI, VESA
DPMS power management,
ISO 13406-2 Class II, cable
management
Designed for integration
100-240V @ 50/60Hz
37W
<2W
16.5 x 16.8 x 7.9 in. /
418 x 427.8 x 199.5mm
16.5 x 14.6 x 2.7 in. /
418 x 369.8 x 68mm
14.3 lbs. / 6.5 kg
12.1 lbs. / 5.5 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours/7 days
AccuSync LCD52V
15"
0.297mm
86 @ native resolution
250 cd/m
2
400:1
110° Vert., 140° Hor.
(55U/55D/70L/70R)
Rapid Response (25ms)
More than 16 million
31.5-60 kHz
56-75 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
15-pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1024 x 768 @ 75 Hz
NaViSet software, digital
smoothing, digital controls,
user (OSM) controls, Plug and
Play (VESA DDC & 2Bi),
AccuColor color control,
DDC/CI, VESA DPMS power
management, ISO 13406-2
Class II, cable management
Designed for integration
100-240V @ 50/60 Hz
21W
<2W
13.6 x 13.9 x 6.5 in. /
344.6 x 352.7 x 165mm
13.6 x 11.2 x 2.3 in. /
344.6 x 285 x 57.5mm
7.1 lbs. / 3.2 kg
6.2 lbs. / 2.8 kg
75 x 75mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,142m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours / 7 days
AccuSync LCD72VM
17"
0.264mm
96 @ native resolution
250 cd/m
2
450:1
145° Vert., 160° Hor.
(75U/70D/80L/80R)
Rapid Response (16ms)
More than 16 million
31.5-81 kHz
56-75 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
15-pin D-sub
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Bezel-integrated speakers,
NaViSet software, digital
smoothing, digital controls,
user (OSM) controls, Plug
and Play (VESA DDC2B & 2Bi),
AccuColor color control,
DDC/CI, VESA DPMS power
management, ISO 13406-2
Class II, cable management
Designed for integration
100-240V @ 50/60 Hz
34W
<2W
14.8 x 15.3 x 7.1 in. /
375.4 x 389 x 180mm
14.8 x 12.9 x 2.4 in. /
375.4 x 326.5 x 61mm
10.4 lbs. / 4.7 kg
9.5 lbs. / 4.3 kg
100 x 100mm
5-35°C / 41-95°F
10-80%
3048m / 10,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours / 7 days
AccuSync LCD200VX
20.1"
0.255mm
100 @ native resolution
250 cd/m
2
400:1
160° Vert., 160° Hor.
(80U/80D/80L/80R)
Rapid Response (16ms)
More than 16 million
31.5-91.1 kHz
56-85 Hz
Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level
(positive/negative)
Composite Sync: TTL Level
(positive/negative)
Composite Sync on Green
(0.3 Vp-p negative 0.7 Vp-p
positive)
DVI-D and VGA 15-pin D-sub
Analog/Digital
720 x 350 @ 70-85 Hz
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 864 @ 70-85 Hz
1152 x 870 @ 75 Hz
1152 x 900 @ 66 Hz
1280 x 960 @ 60-85 Hz
1280 x 1024 @ 60-85 Hz
1600 x 1200 @ 60 Hz
1600 x 1200 @ 60 Hz
XtraView wide-angle
viewing, No Touch Auto
Adjust, 3rd party
touchscreen and
protective glass
integration, NaViSet
software, digital
smoothing, digital controls,
color control (4-mode
memory + sRGB + NATIVE),
user (OSM) controls,Plug
and Play (VESA
DDC2B/DDC/CI), VESA DPMS
power management, cable
management, ISO 13406-2
Class II, vacation switch,
internal power supply,
swivel at stand base, Sync
on Green,
height-adjustable stand
Designed for integration
100-240V @ 50/60Hz
52W
2W
17.5 x 15.4-18.2 x 8.4 in. /
445 x 391.3-461.7 x 213.6mm
17.5 x 14.3 x 3.1 in. /
445 x 363 x 78.5mm
20.7 lbs. / 9.4 kg
15.2 lbs. / 6.9 kg
100 x 100mm
5-35°C / 41-95°F
30-80%
3658m / 12,000 ft.
-10-60°C / 14-140°F
10-85%
12,192m / 40,000 ft.
3 years parts and labor,
including backlight
24 hours/7 days
