NEC LCD1765 Computer Monitor User Manual


  Open as PDF
of 2

15.0"/38cm 17.0"/43.3cm
.297mm .264mm
86 @ native resolution 86 @ native resolution
225 cd/m
2
225 cd/m
2
350:1 400:1
45U/55D/65L/65R 70U/70D/80L/80R
25.46 ms (full cycle) 16 ms (full cycle)
More than 16 million More than 16 million
31.5-60 kHz 31.5-81.1 kHz
56-75 Hz 56-75 Hz
Analog 0.7 Vp-p/75 Ohms Analog 0.7 Vp-p/75 Ohms
Separate Sync:TTL Level (positive/negative) Separate Sync:TTL Level (positive/negative)
Analog VGA 15 pin D-sub Analog VGA 15 pin D-sub
640 x 400 @ 70 Hz 720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz 640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz 800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz 832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz 1024 x 768 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-75 Hz
1024 x 768 @ 75 Hz 1280 x 1024 @ 75 Hz
12V DC,2.5A 12V DC,3A
23W 35W
2W 2W
2W 2W
14.9 x 13.1 x 7.8 in./378.5 x 331.5 x 198 mm 16.6 x 15.3 x 9.6 in./421.9 x 389 x 243.6mm
17.7 x 16.7 x 4.5 in./450 x 425 x 115 mm 20.5 x 16.7 x 6.1 in./520 x 425 x 155mm
8.6 lbs./3.9 kg 13.2 lbs./6.0 kg
12.1 lbs./5.5 kg 17.6 lbs./8.0 kg
5-35
o
C/41-95
o
F5-35
o
C/41-95
o
F
30-80% 30-80%
3,048m/10,000 ft. 3,048m/10,000 ft.
-10-60
o
C/14-140
o
F-10-60
o
C/14-140
o
F
10-85% 10-85%
12,192m/40,000 ft. 12,192m/40,000 ft.
1 year parts and labor,including backlight 1 year parts and labor,including backlight
24 hours/7 days 24 hours/7 days
MultiSync is a registered trademark of NEC-Mitsubishi Electronics Display of
America. All other brand or product names are trademarks or registered
trademarks of their respective holders.06/03 ver.1.
NEC-Mitsubishi Electronics Display of America
1250 North Arlington Heights Road
Itasca,Illinois 60143-1248
Model
Display
Viewable Size Image
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Input
Resolutions Supported
Native Resolution
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Power Off Mode
Dimensions (W x H x D)
Net (with stand)
Gross
Weight
Net (with stand)
Gross
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
MultiSync LCD1565 MultiSync LCD1765
