NEC LCD1920NX Computer Monitor User Manual


  Open as PDF
of 2

NEC-Mitsubishi Electronics Display of America
1250 North Arlington Heights Road
Itasca, Illinois 60143-1248
888-NEC-MITS
www.necmitsubishi.com
MultiSync LCD1700NX MultiSync LCD1920NX
17"/43.26cm 19"/48.19cm
.264mm .294mm
96 @ native resolution 86 @ native resolution
200 cd/m
2
250 cd/m
2
300:1 500:1
85/85/85/85 (U/D/L/R) 85/85/85/85 (U/D/L/R)
Rapid Response (30ms) Rapid Response (25ms)
More than 16 million More than 16 million
31.5-81.1 kHz 31.5-80 kHz
56-76 Hz 56-75 Hz
Analog 0.7 Vp-p/75 Ohms Analog 0.7 Vp-p/75 Ohms
Separate Sync:TTL Level (positive/negative) Separate Sync: TTL Level (positive/negative)
Composite Sync: TTL Level (positive/negative)
DVI-D and VGA 15 pin D-sub DVI-D and VGA 15 pin D-sub
Analog: Digital: Analog: Digital:
720 x 400 @ 70 Hz 720 x 400 @ 70 Hz 720 x 400 @ 70 Hz 720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz 640 x 480 @ 60-75 Hz 640 x 480 @ 60-75 Hz 640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz 800 x 600 @ 56-75 Hz 800 x 600 @ 56-75 Hz 800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz 832 x 624 @ 75 Hz 832 x 624 @ 75 Hz 832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz 1024 x 768 @ 60-75 Hz 1024 x 768 @ 60-75 Hz 1024 x 768 @ 60-75 Hz
1152 x 870 @ 75 Hz 1280 x 1024 @ 60 Hz 1152 x 870 @ 75 Hz 1152 x 870 @ 75 Hz
1280 x 1024 @ 60-76 Hz 1280 x 1024 @ 60-75 Hz 1280 x 1024 @ 60-75 Hz
(60 Hz is recommended) (60 Hz is recommended)
LiquidView, XtraView+ technology,Digital Smoothing, Digital XtraView technology, Auto Adjust, Digital Smoothing, Digital
Controls, Plug and Play (VESA DDC2B&2Bi), VESA DPMS power Controls, Plug and Play (VESA DDC2B&2Bi)VESA DPMS power
management, User OSM controls, ISO 13406-2 Class 2 management, User OSM controls, ISO 13406-2 Class 2
Universal 100 (110-240V)50-60 Hz Universal 100 (110-240V)50-60 Hz
41W 38W
3W 3W
17.1 x 17.2 x 8.7 in./434 x 437 x 220mm 17.1 x 16.7 x 8.1 in./434.5 x 423 x 205mm
17.1 x 15.1 x 2.8 in./434 x 384.2 x 71.5mm 17.1 x 15 x 2.7 in./434.5 x 380 x 69.5mm
13.7 lbs./6.2 kg 17.6 lbs./8.0 kg
10.4 lbs./4.7 kg 14.3 lbs./6.5 kg
100mm x 100mm 100mm x 100mm
5-35
o
C/41-95
o
F5-35
o
C/41-95
o
F
30-80% 10-80%
3,658m/12,000 ft. 3,000m/9,843 ft.
-10-60
o
C/14-140
o
F-10-60
o
C/14-140
o
F
10-85% 10-85%
12,192m/40,000 ft. 12,000m/39,370 ft.
3 years parts and labor,including backlight 3 years parts and labor,including backlight
24 hours/7 days 24 hours/7 days
Model
Display
Viewable Size Image
Pixel Pitch
Pixels Per Inch
Brightness
Contrast Ratio
Viewing Angle
Response Time
Display Colors
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Input
Resolutions Supported
Additional Features
Voltage Rating
Power Consumption
On:
Power Savings Mode:
Dimensions (W x H x D)
Net (with stand)
Net (without stand)
Net Weight
(with stand)
(without stand)
VESA Hole Configuration Specifications
Environmental Conditions
Operating Temperature:
Operating Humidity:
Operating Altitude:
Storage Temperature:
Storage Humidity:
Storage Altitude:
Limited Warranty
Technical Support
MultiSync,AccuColor and XtraView are registered trademarks and XtraView+,
Rapid Response, LCD1700NX, LCD1920NX are trademarks of NEC-Mitsubishi
Electronics Display of America. All other brand or product names are trade-
marks or registered trademarks of their respective holders. 6/02 ver.1.
