OSM
™
(On-Screen-Manager) Controls
The OSM controls on the front of the monitor function as follows:
Control Main Menu Sub-Menu
EXIT Exits the OSM controls. Exits to the OSM controls
main menu.
CONTROL / Moves the highlighted Moves the highlighted area
area up/down to select up/down to select one of the
one of the controls. controls.
CONTROL –/+ Has no function. Moves the bar in the + or –
direction to increase or
decrease the adjustment.
PROCEED Proceeds to the selected Activates Auto Adjust feature.
menu choice (indicated In Display Mode, opens
by the highlighted area). additional window.
RESET: The currently Resets all the controls within Resets the highlighted control.
highlighted control to the highlighted menu.
the factory setting.
NOTE: When RESET is pressed, a warning window will appear
allowing you to cancel the reset function.
Brightness and Contrast
Brightness: Adjusts the overall image and background screen brightness.
Contrast: Adjusts the image brightness in relation to the background.
Auto Adjust Contrast: Corrects the image displayed for non-standard video inputs.
Auto Adjust
Allows automatic adjustment of the Position and Image Adjust controls.
Position
Controls horizontal and vertical image position within the display
area of the LCD.
Auto Adjust Position: Automatically sets the horizontal and vertical image
position within the display area of the LCD.
Image Adjust
Coarse: Adjusts the horizontal size by increasing or decreasing the Coarse setting.
Fine: Improves focus, clarity and image stability by increasing or
decreasing the Fine setting.
Auto Adjust Coarse/Fine: Automatically adjusts the Coarse or Fine settings.
Controls
