Oregon Scientific JM889N Clock User Manual



3
EN
Back View
LCD Display Symbols
Icon Description Explanation
Radio Reception
Signal
Indicates the condition of radio reception.
Low Battery Appears when power is low.
Alarm-on Appears when alarm is activated.
Alarm Time
Indicator
Appears when alarm time is displayed.
5. Wall-Mount Recess Hole
For mounting the unit to a wall
6. Alarm Button
Display and adjust alarm time
7. Clock Button
Manually adjust current time and date
8. Reset Hole
Returns all settings to default values.
9. Button
Used to adjust settings down one notch or to enable/disable
RF radio reception
10. Button
Used to adjust settings up one notch or to enable/disable
RF radio reception
11. Battery Compartment
The unit uses 2 AA 1.5V batteries for power.
12. Table Stand
Can be pulled out and used to stand the unit on a flat surface
5
6
7
8
9
10
11
12
