RS416 -______ -______ -____ -____ -____ -____ -____ -____ -____ -____
Main Mount PS1 PS2 S1 S2 S3 S4 S5 S6
Main: Ethernet and Power Connectors
.
R = Ethernet on rear; LED panel on front; power connector on rear
.
F = Ethernet on front; LED panel on front; power connector on rear
.
B = Ethernet on rear; LED panel on top; power connector on rear
.
T = Ethernet on front; LED panel on top; power connector on rear
Mount: Mounting Options
.
RM = 19" Rack Mount Kit
.
DP = DIN and Panel Mount Kit
.
RD = 19" Rack, DIN, and Panel Mount Kit
.
00 = No Mounting Option
PS1 and PS2: Power Supply 1 and 2
.
24 = 24VDC (9-36VDC), screw terminal block
.
48 = 48VDC (36-59VDC), screw terminal block
.
HI = 88-300VDC or 85-264VAC, screw terminal block
.
24P = 24VDC (9-36VDC), pluggable terminal block
.
48P = 48VDC (36-59VDC), pluggable terminal block
.
HIP = 88-300VDC or 85-264VAC, pluggable terminal block
.
XX = No Power Supply (PS2 Only)
S1, S2, S3, S4: Serial Port Modules for Slots 1, 2, 3, and 4
.
XX = Empty (S2,S3,S4 Only)
.
3D = 4 x RS232/RS422/RS485 via DB9
.
3R = 4 x RS232/RS422/RS485 via RJ45
.
FS = Fiber Serial Interface (ST Connector)
S5, S6: Ethernet Modules for Slots 5 and 6
.
XXXX = Empty (S6 Only)
.
TX01 = 2 x 10/100Tx RJ45
.
FL01 = 2 x 10FL - Multimode, 850nm, ST
.
FX01 = 2 x 100FX - Multimode, 1300nm, ST
.
FX02 = 2 x 100FX - Multimode, 1300nm, SC
.
FX11 = 2 x 100FX – Multimode, 1300nm, LC
.
FX03 = 2 x 100FX - Multimode, 1300nm, MTRJ
.
FX04 = 2 x 100FX - Singlemode, 1300nm, ST, 20km
.
FX05 = 2 x 100FX - Singlemode, 1300nm, SC, 20km
.
FX06 = 2 x 100FX - Singlemode, 1300nm, LC, 20km
.
FX07 = 2 x 100FX - Singlemode, 1300nm, SC, 50km
.
FX08 = 2 x 100FX - Singlemode, 1300nm, LC, 50km
.
FX09 = 2 x 100FX - Singlemode, 1300nm, SC, 90km
.
FX10 = 2 x 100FX - Singlemode, 1300nm, LC, 90km
Order Codes
www.RuggedCom.com
9
RuggedServer™ RS416
RuggedServer™ RS416
Modular 16-Port Serial Device Server with Integrated Managed Ethernet Switch
Example Order Codes:
RS416-R-RM-24-XX-3D-3D-XX-XX-TX01-XXXX
19" Rack mounted, 24VDC power supply, 2 10/100 RJ45 Ethernet
Ports, 8 DB9 Serial Ports, with all Ports on the rear
RS416-F-RM-48-48-3R-3R-3R-3R-FX01-FX01
19" Rack mounted, Dual 48VDC power supply, 4 100FX (Multi
Mode 1300nm Fiber) Ethernet ports, 16 RJ45 Serial Ports, with all
Ports on the front
RS416-F-RM-HI-XX-3R-3R-3D-3D-FX01-TX01
19" Rack mounted, HI power supply, 2 100FX (Multi Mode
1300nm Fiber) Ethernet Ports, 2 10/100 RJ45 Ethernet Ports, 8
RJ45 Serial Ports, 8 DB9 Serial Ports, with all Ports on the front
Accessories/Options
82-01-0002 - Conformal Coating
41-11-0011 - Cable support brackets
43-10-0007 - Power cable (North America three
prong connector -> beau)
Slot 5
Slot 6
RS416
Slot 1
Slot 2
Slot 3
Slot 4
