RuggedVDSL
TM
RS900L
RuggedVDSL™ RS900L
8-Port Managed Ethernet Switch with Ethernet Over VDSL Uplinks
RS900L -___ - ___ - ___- ___- ____
PS M P7 P8 VV
Base Unit includes One Ethernet over VDSL interface and 6
10/100BaseTX Ethernet ports.
PS: Power Supply
.
24 = 24 VDC (9-36VDC)
.
48 = 48 VDC (36-72VDC)
.
HI = 87-264VAC OR 88-300VDC
M: Mounting Option
.
D = DIN Rail
.
P = Panel Mount
.
N = None
P7, P8: Additional Ethernet Ports
.
XX = None
.
TX = 1 x 10/100BaseTX (if selected, P7 & P8 must both be TX)
.
MJ = Multimode 1300nm, MTRJ connector
.
MC = Multimode 1300nm, SC connector
.
MT = Multimode 1300nm, ST connector
.
ML = Multimode 1300nm, LC connector
.
T2 = Singlemode 1310nm, ST connector, Standard 20km
.
L2 = Singlemode 1310nm, LC connector, Standard 20km
.
L5 = Singlemode 1310nm, LC connector, Intermediate Reach 50km
.
L9 = Singlemode 1310nm, LC connector, Long Reach 90km
.
C2 = Singlemode 1310nm, SC connector, Standard 20km
.
C5 = Singlemode 1310nm, SC connector, Intermediate Reach 50km
.
C9 = Singlemode 1310nm, SC connector, Long Reach 90km
VV: VDSL Interface
V1 = Standard reach (<2.5km)
V2 = Long Reach (5km) Master / CO
V3 = Long Reach (5km) / CPE
Options
82-01-0002 - Conformal Coating
Power Cables
43-10-0008 - Bare-wire
43-10-0007 - with lugs
RuggedCom Inc.
30 Whitmore Road
Woodbridge, Ontario, Canada L4L 7Z4
Tel: (905) 856-5288 Fax: (905) 856-1995
Toll Free: (888) 264-0006
Technical Support Center: (866) 922-7975 or (954) 922-7975
© 2007 RuggedCom Inc.
RuggedVDSL is a trademark of RuggedCom Inc.
Ethernet is a trademark of the Xerox Corporation.
Patent Pending
All specifications in this document are subject to change without notice.
Rev 1-N
For additional information on our products and
services, please visit our web site at: www.ruggedcom.com
Order Codes
